uDio onnection
Microphone inputs are via XLR 3-pin female connectors.
The line-level outputs are accessed on a 25-way D-type female connector. A pin-to-pin individually screened, balanced
audio cable should be used to connect the 8-RMP output to one of the Alpha-Link LIVE-R analogue input connectors.
Standard cables are available to order in 1m, 5m, 10m and 25m lengths.
The maximum recommended length of the audio cable between Alpha-Link LIVE-R and 8-RMP is 50m.
r c
emote ontroL
A separate RJ45 lead must be installed to provide control for the Gain, Pad and Phantom Power settings. Where connection
is made to an Alpha-Link LIVE-R then standard Ethernet cables can be used.
Alpha-Link Live units use a custom pinout for the 'Remote' connector so standard Ethernet network leads cannot be used. If
making your own cables, refer to page 6-10 for the pinout of the custom control lead.
Audio and control leads are available to order in standard 1m, 5m, 10m and 25m lengths.
i Refer to page 6-12 for the connector pinouts.
r iD
emote conFiguration
The 8-RMP units are configured with an identification number (ID-1, 2 or 3) via the front panel buttons to match the
corresponding 'Remote' port used on the controlling Alpha-Link. A unit configured to be ID-1, for example, will not
respond if connected to Alpha-Link LIVE-R 'Remote' ports 2 or 3.
T C T C
O OnFIGuRE HE
a. Switch off the power, remove the RJ45 control lead and re-apply power to the 8-RMP unit.
If the unit is already communication with the Alpha-Link LIVE-R it will not be possible to alter the configuration.
b. Press and hold the 'TYPE' and 'GAIN switches
This will enter the configuration mode.
c. The '0' level LED
This indicates that the unit is in its channel ID setup mode. (If either the '10' or '16' LEDs is lit instead then press the
'INPUT' button once or twice until the '0' LED lights).
d. One of the '+48v' lights
This indicates the current channel ID number.
e. To alter the current channel ID number press the 'UP' or 'DOWN' buttons
required channel is indicated.
NB. It is possible to set channel numbers above ID3. Settings ID4 and above are invalid and will result in a loss of control
of the unit.
f. Press the 'TYPE' and 'GAIN switches down together for about 1 second.
This will exit the configuration mode. Remember to reconnect the control lead.
