Solid State Logic C10 HD Installation Manual page 41

a -L 8-rmP
LPha ink
The RMP is an 8-channel microphone amplifier in a 2U high 300mm deep 19" rack unit. It features dual power supplies for
on-air reliability. Switchable phantom power is available on each input.
The 8-RMPs connect directly to an Alpha-Link LIVE-R unit, not to the console surface. Up to three units can be connected
to each Alpha-Link LIVE-R.
a c
uDio anD ontroL
Analogue outputs from the 8-RMP are at line level and should be connected to an Alpha-Link LIVE-R using 8-circuit
balanced audio cable.
Remote control information is provided by a separate RJ45 data cable.* Pairs of audio-plus-control cables can be ordered
from SSL in lengths of 1m, 5m, 10m and 25m. Cable pinouts are listed in the appendices. The maximum recommended
cable length between each Alpha-link 8-RMP and an Alpha-Link LIVE-R is 50m.
c S
onnector ummary
name Connector
Mic/Line In XLR3 F
Line Out D25 F
Remote RJ45
i See Section 6-12 for the connector pinouts.
*Pinout of the data cable will differ depending on whether Alpha-Link Live or Alpha-Link LIVE-R is being used. Refer to previous
section for further information.
C10 HD Installation Manual
c
abLeS
Description
Microphone input. Pin 2 +ve. Switchable phantom power.
8 channel balanced audio outputs, line level.
Control data connection to Alpha-Link LIVE-R.*
System Components
Section 2: Preparation | Page 2-21
