Naming Softkey Assignments - Solid State Logic C10 HD Installation Manual

B: Console Configuration
‰ When Auto increment is active, clear the keyboard after your last entry by selecting cancel on the on-screen
keyboard.
‰ For additional characters, press the Symbols box on the on-screen keyboard.
You can name all busses with the same prefix followed by the channel number (when using a different language, for example):
‰ Once the bus type is selected, touch the Rename All button.
‰ Enter a new name of up to 6 characters, using the on-screen keyboard which appears, and press ok.
Note that one version of the Names data is held in each Project Version.
n S A
AminG oFtkey SSiGnmentS
Once a softkey has been assigned, it is given a default 4-character name which appears in its associated display. This name
can be altered as follows:
‰ Touch the FRee nAme ( ) button in the User Toolbox to open the Free Assign display:
‰ Press the softkey which you want to rename. It's function will appear in the Selected Function box at the top of
the display, and the default name will appear in the default four-character name box in the left of the display.
‰ Touch the Rename button, type the new name in the QWERTY keyboard which appears, and press ok. The new
name will appear in the User four-character name box in the right of the Free Assign display, as well as in the
softkey's associated display.
‰ Press another softkey to rename if required and repeat the process, or touch ok to close the display.
C10 HD Installation Guide Section 4: Configuration | Page 4-31
