Channel Capacity - Solid State Logic C10 HD Installation Manual

Installation Cabling
c c
hanneL aPacity
All I/O units use the standard for audio data transfer; the maximum data capacity of each fibre run is therefore
MADI 64
channels.
Specifically, Alpha-Link Live units use up to 48 channels; MORSE stageboxes use up to 56 channels per MADI link.
F c e (S o )
ibre abLing xamPLeS ee PPoSite
The number of fibre connections that will need to be run between the processor and each remote i/o locations will depend
on the type of connection chosen.
All I/O units are fitted with two audio connectors to facilitate the installation of redundant audio links.
