‰ Once a name is entered, a new pop-up will appear asking you to Select path to save from. Press the Att
button on the channel strip that has the correct settings to be saved in this preset, or select the channel from the on-
screen list:
‰ Press ok and the selected settings will be copied from the channel and stored as a preset on the console's hard disk,
with the name that you gave. It will also be listed in the left-hand window with all other presets, arranged in the order
they were created.
‰ To delete a Preset, highlight the unwanted preset in the preset library load/Save pop up and press the
Remove preset box.
There are a number of default Presets included in the console which can be used as a starting point:
eQ
p :
ReSetS
SHELF EQ
WITH FILTERS
4-BAND
DEFAULT EQ
HPF +
3-BAND EQ
4-BAND
PARAMETRIC EQ
dynamic

presets:

PGM
LIMITER*
VOX
COMP
All EQ Presets are initially set as flat.
*The PGM Limiter also has a feed forward delay of 1ms.
C10 HD Installation Guide
B 1
And
Hi-Pass Filter, 500Hz Lo-Shelf,
24dB per octave
200Hz Lo-Shelf, 400Hz Parametric
Q = 0.4
Hi-Pass Filter, 200Hz Lo-Shelf,
24dB per octave
80Hz Parametric 400Hz Parametric
Q=0.4
R
Atio
(Limit)
10:1
B 2 B
And And
1.5kHz Hi-Shelf,
Q = 0.4 Q = 0.4
3kHz Parametric
Q=0.5 Q=0.5
500Hz Parametric
Q = 0.5
3kHz Parametric
Q=0.5 Q=0.5
R
eleASe
t
hReShold
A
ttAck
100ms
0.7ms
251ms
1ms
Section 4: Configuration
B: Console Configuration
3 B
And
Lo-Pass Filter,
12dB per octave
5kHz Hi-Shelf,
Q = 0.4
3kHz Hi-Shelf,
Q=1 Q = 0.4
5kHz Parametric
Q=0.4
G
Ain
6dB 0dB
12dB 3dB
4
