3
Setup of Hand Guiding Function
3.7
Setting of Sensor Mounting Angle
3-12
HW1485706
I084 (X): 90
I085 (Y): -45
I086 (Z): 0
I084 (X): 90
I085 (Y): 45
I086 (Z): 90
I084 (X): 90
I085 (Y): -45
I086 (Z): 90
I084 (X): -90
I085 (Y): -45
I086 (Z): -90
I084 (X): -90
I085 (Y): 45
I086 (Z): -90
HW1485706
30/58
