Oracle Acme Packet 1100 Hardware Installation Manual page 48

SPECIFICATIONS
AC Power Supply
Specifications
DRAFT
Power Supply
Input Circuit Fuse
Requirements
Proprietary and Confidential
48
Table 7 - 3. AC Power Supply Specifications
Specification Fuse Rating
Voltage Autoranging 100 AC to 240 AC wide input with power factor correction
Frequency 50/60 Hz
Current 12v x 0.75A
Cable 2.0 m 18 AWG three-wire cable with three-lead IEC 320 receptacle on the
power supply end and a country-dependent plug on the power source end
Power 300 VA maximum
Type External, field-replaceable
Table 7 - 4. Acme Packet 1100 Power Supply Input Circuit Fuse Requirements
Power Circuit Fuse Rating
120 VAC 15 AMP
240 VAC 7.5 AMP
Power cable size
18 AWG
18 AWG
Acme Packet 1100 Hardware Installation Guide
