Power Cycling
DRAFT

Forcing Switchover for HA Nodes

Proprietary and Confidential
Caution
Acme Packet 1100 Hardware Installation Guide
To reset the Acme Packet 1100:
1. Insert a rigid paperclip-sized tool into the small hole on the rear of the chassis
as indicated in the following graphic. The system immediately resets and begins
its initialization and boot sequence.
LNK ACT LNK ACT LNK ACT LNK
SER MGT NET MGT INT EXT
Figure 6 - 1. Reset Button
Power cycling the system is the process of turning the chassis off and then on by first
unplugging from and plugging in to the AC power cord to the power supply. It is
imperative that you wait at least 10 seconds between power down and power up to
ensure that all components are completely powered down before restart.
Note: Power cycling the Acme Packet 1100 without performing a halt
operation can lead to data loss to the storage device. To ensure stable
operation, a file system check is performed upon the next power up.
This check may take several minutes to complete, and should not be
interrupted.
When performing hardware maintenance on the Acme Packet 1100, it is best to
minimize any risk of interrupting network traffic or losing data. If the Acme Packet
1100 is configured as an HA node, only work on the Acme Packet 1100 that is in
standby mode.
To determine the HA state of each Acme Packet 1100 in an HA pair, review the HA
LED on the front panel or use the ACLI show health command. Once the Acme
Packet 1100 due for maintenance is in standby mode, continue with the appropriate
procedures to service it.
To perform maintenance on the active Acme Packet 1100, manually force the two
Acme Packet 1100s to switch HA states. Performing a switchover forces the currently
active Acme Packet 1100 to standby mode while the current standby Acme Packet
1100 will become the active system, assuming all traffic processing and forwarding.
The following procedure is only applicable to Acme Packet
1100s in an HA deployment.
ACT
MAINTENANCE INTRODUCTION
12V
39
