Cooling System Maintenance

DRAFT
Maintaining the
Cooling
Components
Caution
Proprietary and Confidential
Acme Packet 1100 Hardware Installation Guide
5. Using a Philipps head screwdriver, insert and tighten the three screws indicated
by the red circles in the following illustration.
LNK ACT LNK ACT LNK ACT LNK
SER MGT NET MGT INT EXT
Figure 6 - 8. Acme Packet 1100 - Rear Panel
This section explains how to service the cooling system on your Acme Packet 1100.
To prevent system malfunction and prolong the life of the system cooling
components, clean the air inlets on the left and right sides of the chassis once a week.
To lean the inlets, gently wipe the perforated air inlets with a clean, dry cloth.
To prevent damage to the painted finish, do not use any
solvents or liquids to clean the perforated air inlets on the
front of the chassis.
ACT
MAINTENANCE INTRODUCTION
12V
