Command Usage
• For Fast Ethernet interfaces, the rate limit granularity is 512 Kbps, 1 Mbps, or
3.3 Mbps.
• For Gigabit Ethernet interfaces, the rate limit granularity is 33.3 Mbps.
Example
Console#show rate-limit
Fast ethernet granularity:
Gigabit ethernet granularity:
Console#

Link Aggregation Commands

Ports can be statically grouped into an aggregate link (i.e., trunk) to increase the
bandwidth of a network connection or to ensure fault recovery. Or you can use the
Link Aggregation Control Protocol (LACP) to automatically negotiate a trunk link
between this switch and another network device. For static trunks, the switches have
to comply with the Cisco EtherChannel standard. For dynamic trunks, the switches
have to comply with LACP. This switch supports up to four trunks. For example, a
trunk consisting of two 1000 Mbps ports can support an aggregate bandwidth of
4 Gbps when operating at full duplex.
Command
Manual Configuration Commands
interface port-channel
channel-group
Dynamic Configuration Command
lacp
lacp system-priority
lacp admin-key
lacp admin-key
lacp port-priority
Trunk Status Display Command
show interfaces status
port-channel
show lacp
3300
33000

Table 4-43. Link Aggregation Commands

Function
Configures a trunk and enters interface
configuration mode for the trunk
Adds a port to a trunk
Configures LACP for the current interface
Configures a port's LACP system priority
Configures a port's administration key
Configures an port channel's administration key
Configures a port's LACP port priority
Shows trunk information
Shows LACP information
Link Aggregation Commands
Mode
GC
IC (Port Channel)
IC (Ethernet)
IC (Ethernet)
IC (Ethernet)
IC (Port Channel)
IC (Ethernet)
NE, PE
PE
4
Page
4-104
4-120
4-121
4-122
4-123
4-124
4-125
4-111
4-125
4-119
