CLI – This example assigns a multicast address to VLAN 1, and then displays all the
known multicast services supported on VLAN 1.
Console(config)#ip igmp snooping vlan 1 static 224.1.1.12
ethernet 1/12
Console(config)#exit
Console#show mac-address-table multicast vlan 1
VLAN M'cast IP addr. Member ports Type
---- --------------- ------------ -------
1
224.1.1.12
1
224.1.2.3
Console#
Eth1/12
USER
Eth1/12
IGMP
3
Multicast Filtering
4-177
4-179
3-139
