4
Command Line Interface
an STA-compliant switch, bridge or router) in your network to ensure that only
one route exists between any two stations on the network, and provide backup
links which automatically take over when a primary link goes down.
Example
This example shows how to enable the Spanning Tree Algorithm for the switch:
Console(config)#spanning-tree
Console(config)#

spanning-tree mode

This command selects the spanning tree mode for this switch. Use the no form to
restore the default.
Syntax
spanning-tree mode {stp | rstp}
no spanning-tree mode
• stp - Spanning Tree Protocol (IEEE 802.1D)
• rstp - Rapid Spanning Tree Protocol (IEEE 802.1w)
Default Setting
rstp
Command Mode
Global Configuration
Command Usage
• Spanning Tree Protocol
Uses RSTP for the internal state machine, but sends only 802.1D BPDUs.
• Rapid Spanning Tree Protocol
RSTP supports connections to either STP or RSTP nodes by monitoring
the incoming protocol messages and dynamically adjusting the type of
protocol messages the RSTP node transmits, as described below:
- STP Mode – If the switch receives an 802.1D BPDU after a port's migration
delay timer expires, the switch assumes it is connected to an 802.1D bridge
and starts using only 802.1D BPDUs.
- RSTP Mode – If RSTP is using 802.1D BPDUs on a port and receives an
RSTP BPDU after the migration delay expires, RSTP restarts the migration
delay timer and begins using RSTP BPDUs on that port.
Example
The following example configures the switch to use Rapid Spanning Tree:
Console(config)#spanning-tree mode rstp
Console(config)#
4-134
