4
Command Line Interface
Default Setting
auto
Command Mode
Interface Configuration (Ethernet, Port Channel)
Command Usage
• Specify a point-to-point link if the interface can only be connected to exactly
one other bridge, or a shared link if it can be connected to two or more bridges.
• When automatic detection is selected, the switch derives the link type from the
duplex mode. A full-duplex interface is considered a point-to-point link, while
a half-duplex interface is assumed to be on a shared link.
• RSTP only works on point-to-point links between two bridges. If you designate
a port as a shared link, RSTP is forbidden.
Example
Console(config)#interface ethernet 1/5
Console(config-if)#spanning-tree link-type point-to-point

spanning-tree protocol-migration

This command re-checks the appropriate BPDU format to send on the selected
interface.
Syntax
spanning-tree protocol-migration interface
interface
• ethernet unit/port
- unit - This is device 1.
- port - Port number.
• port-channel channel-id (Range: 1-4)
Command Mode
Privileged Exec
Command Usage
If at any time the switch detects STP BPDUs, including Configuration or
Topology Change Notification BPDUs, it will automatically set the selected
interface to forced STP-compatible mode. However, you can also use the
spanning-tree protocol-migration command at any time to manually
re-check the appropriate BPDU format to send on the selected interfaces (i.e.,
RSTP or STP-compatible).
4-142
