Manual Configuration

Web – Click System, IP Configuration. Select the VLAN through which the
management station is attached, set the IP Address Mode to "Static," enter the IP
address, subnet mask and gateway, then click Apply.
CLI – Specify the management interface, IP address and default gateway.
Console#config
Console(config)#interface vlan 1
Console(config-if)#ip address 10.1.0.254 255.255.255.0
Console(config-if)#exit
Console(config)#ip default-gateway 192.168.1.254
Console(config)#

Figure 3-6. IP Configuration
