Related Commands
garp timer (4-161)

Priority Commands

The commands described in this section allow you to specify which data packets
have greater precedence when traffic is buffered in the switch due to congestion.
This switch supports CoS with four priority queues for each port. Data packets in a
port's high-priority queue will be transmitted before those in the lower-priority
queues. You can set the default priority for each interface, the relative weight of each
queue, and the mapping of frame priority tags to the switch's priority queues.
Command Groups
Priority (Layer 2)
Priority (Layer 3 and 4)

Priority Commands (Layer 2)

Command
queue mode
queue bandwidth
switchport priority default
queue cos map
show queue mode
show queue bandwidth
show queue cos-map
show interfaces switchport Displays the administrative and operational status of an

Table 4-56. Priority Commands

Function
Configures default priority for untagged frames, sets queue weights,
and maps class of service tags to hardware queues
Maps TCP ports, IP precedence tags, or IP DSCP tags to class of
service values

Table 4-57. Priority Commands (Layer 2)

Function
Sets the queue mode to strict priority or Weighted
Round-Robin (WRR)
Assigns round-robin weights to the priority queues
Sets a port priority for incoming untagged frames
Assigns class-of-service values to the priority queues
Shows the current queue mode
Shows round-robin weights assigned to the priority queues
Shows the class-of-service map
interface
Priority Commands
Page
4-163
4-169
Mode Page
GC 4-164
GC 4-164
IC 4-165
IC 4-166
PE 4-167
PE 4-167
PE 4-168
PE 4-113
4-163
4
