Console#show lacp 1 internal
Channel group : 1
-------------------------------------------------------------------------
Oper Key : 4
Admin Key : 0
Eth 1/1
-------------------------------------------------------------------------
LACPDUs Internal : 30 sec
LACP System Priority : 32768
LACP Port Priority : 32768
Admin Key : 4
Oper Key : 4
Admin State : defaulted, aggregation, long timeout, LACP-activity
Oper State : distributing, collecting, synchronization, aggregation,
long timeout, LACP-activity
. .
.

Table 4-45. show lacp internal - display description

Field Description
Oper Key Current operational value of the key for the aggregation port.
Admin Key Current administrative value of the key for the aggregation port.
LACPDUs Internal Number of seconds before invalidating received LACPDU information.
LACP System Priority LACP system priority assigned to this port channel.
LACP Port Priority LACP port priority assigned to this interface within the channel group.
Admin State, Administrative or operational values of the actor's state parameters:
Oper State • Expired – The actor's receive machine is in the expired state;
• Defaulted – The actor's receive machine is using defaulted operational partner
• Distributing – If false, distribution of outgoing frames on this link is disabled; i.e.,
• Collecting – Collection of incoming frames on this link is enabled; i.e., collection is
• Synchronization – The System considers this link to be IN_SYNC; i.e., it has been
• Aggregation – The system considers this link to be aggregatable; i.e., a potential
• Long timeout – Periodic transmission of LACPDUs uses a slow transmission rate.
• LACP-Activity – Activity control value with regard to this link. (0: Passive; 1: Active)
information, administratively configured for the partner.
distribution is currently disabled and is not expected to be enabled in the absence
of administrative changes or changes in received protocol information.
currently enabled and is not expected to be disabled in the absence of
administrative changes or changes in received protocol information.
allocated to the correct Link Aggregation Group, the group has been associated
with a compatible Aggregator, and the identity of the Link Aggregation Group is
consistent with the System ID and operational Key information transmitted.
candidate for aggregation.
