IP Settings / Options Dialog Box

The IP Settings / Options dialog box (click
provides a location for viewing and, if connected via either serial port or if logged on via
the Ethernet port as an administrator, editing settings unique to the Ethernet interface (see
Ethernet Connection
fields on this screen can be edited while you are logged on as a user.
Figure 22.
NOTES:
Editing variables in the
•
the Ethernet port can immediately disconnect the user from the switcher. Extron
recommends editing the settings on this screen using a serial port and protecting
the Ethernet access to this screen by assigning an administrator password to
qualified and knowledgeable personnel only.
• When the control program is connected to the switcher via the RS-232 link,
the
password has been inadvertently changed to an unknown value, you can look up
and change a password in this dialog box without knowing the current password.
on page 82 for basic information about IP addresses). None of the
Control Program IP Setting/Options Dialog Box
IP Settings / Options
Administrator Password
FOX Matrix 320x and FOX Matrix 14400 • Matrix Software
>
Tools IP options
dialog box while connected via
and fields are not masked. If a
User Password
, see figure 22)
43
