Administrator Password and User Password fields
The
Administrator Password
switcher via the Ethernet port with all of the rights and privileges of an administrator. The
field displays the password required to log on to the matrix switcher via
User Password
the Ethernet port as a user, without all of the rights and privileges of an administrator.
Passwords are case sensitive and are limited to 12 upper-case and lower-case
alphanumeric characters.
Both password fields are masked with asterisks (
NOTES:
• On password-protected connections, there are two levels of protection:
administrator and user. Administrators have full access to all switching capabilities
and editing functions. Users can create ties, create and recall presets, set mutes,
and view all settings with the exception of passwords.
• Editing the Administrator Password field while connected via the Ethernet port can
immediately disconnect the user from the switcher. Extron recommends editing this
field using either serial port and protecting the Ethernet access to this screen by
assigning an administrator password to qualified and knowledgeable personnel only.
• An administrator password must be created before a user password can be
created.
• The HTML language reserves certain characters for specific functions (see
Characters
on page 35).
Edit either password field as follows:
1. Click in the desired
Password
2. Edit the case-sensitive password as desired.
Press the <Tab> key on the keyboard or click in another field to exit the
3.
4. Click the button to make the password change take effect.
Take
Mail Server IP Address field
The
Mail Server IP Address
the email for the facility in which the matrix switcher is installed. Standard IP protocol rules
apply to the Mail Server IP address.
Edit this field as follows:
1. Click in the
Mail Server IP Address
2. Edit the IP address as desired.
3. Press the <Tab> key on the keyboard or click in another field to exit the
field.
Address
4. Click the button to make the address change take effect.
Take
field displays the password required to log on to the matrix
************
field. The pointer tool becomes a text cursor.
field displays the IP address of the mail server that handles
field. The pointer tool becomes a text cursor.
FOX Matrix 320x and FOX Matrix 14400 • Matrix Software
) as a security measure.
Special
field.
Password
Mail Server IP
