Fiber optic I/O board LED indications
On the fiber optic I/O boards, the input and output LEDs on the transceivers provide useful
indications of the status of the lasers and the reclocking function (see the table below).
Definition
Reclocked at 4.25 Gbps
Not reclocked, laser off, or no signal
Non-4G signal present or not reclocked
NOTE: If the reclocking feature is bypassed (see the
command on page 26), the output LED is always on.
3G/HD/SD-SDI boards
Figure 8.
B BNC board, connectors (see
connectors, as follows:
Ï
Ö
Output connector — For all one-way video, audio, and serial communications
output to a receiver, connect a fiber optic cable to the Output LC connector (see
figure 7, on the previous page).
Connect the far end of this fiber optic cable to the Optical Rx LC connector on a
FOXBOX Rx receiver or to any other compatible Extron fiber optic device.
NOTES:
• For a FOX 500 receiver, connect this fiber optic cable to the Optical Rx LC
connector.
Alternatively, for the serial return, (receiver-to-transmitter) function,
•
connect the far end to the Optical 2 connector on a transmitter.
Output LED — See "Fiber optic I/O board LED indications," below.
OUT
Output LED
indication
On
Off
Fast blink
Ï Ï Ï Ï Ï Ï Ï Ï Ï Ï Ï Ï Ï Ï Ï Ï Ï Ï
OUT IN OUT IN OUT IN OUT IN OUT IN OUT
A B C D E F
Ö Ö Ö Ö Ö Ö Ö Ö Ö Ö Ö Ö Ö Ö Ö Ö Ö Ö
3G/HD/SD-SDI Board
Connect inputs and output using the included DIN-to-female-BNC pigtail
NOTE: The pigtails are not installed on the board during shipment.
To install the pigtails, press them onto the DIN connectors until
•
they snap into place.
To remove the pigtails, pull back on the knurled collar and pull the
•
pigtail straight back from the DIN connector.
Multi-rate SDI Input connectors — Connect 3G-SDI, HD-SDI, or SDI
video inputs to these BNC connectors.
Multi-rate SDI Output connectors — Connect digital displays to these BNC
connectors.
IN
Input LED
indication
On Reclocked at 4.25 Gbps
Off Not reclocked or no signal
Fast blink Non-4G signal present or not reclocked
Set output reclocker
Ï Ï Ï Ï Ï Ï Ï Ï Ï Ï Ï Ï Ï Ï Ï
IN OUT IN OUT IN OUT IN OUT IN OUT IN OUT
G H I J K
Ö Ö Ö Ö Ö Ö Ö Ö Ö Ö Ö Ö Ö Ö Ö Ö Ö Ö
figure 3 on page 8 and
FOX Matrix 320x and FOX Matrix 14400 • Installation
Definition
SIS
Ï Ï Ï Ï Ï Ï Ï Ï Ï Ï Ï Ï Ï Ï Ï
3G P BNC
IN OUT IN OUT IN OUT IN OUT IN
L M N O P
Ö Ö Ö Ö Ö Ö Ö Ö Ö Ö Ö Ö
OUT
figure 4 on page 9) —
IN
