The amber buttons indicate ties.
•
• The gray buttons indicate no ties.
If you lose track of the input and output associated with a specific button, let
TIP:
the mouse pointer rest over the button for a moment. As shown on
previous page, a field pops up that identifies the input and output numbers for that
button.
Creating or deleting a tie
Make or break a tie as follows:
Move the mouse over the matrix of input and output selection buttons. Click a button
1.
to:
• Create a pending tie (if a tie does not exist) of the input and output associated with
that button.
• Create a pending untie (if a tie exists) of the input and output associated with that
button.
A " " (for pending) appears in the button.
P
NOTES:
• Because of command length limitations in the browser, you can make a
maximum of 30 connections with a single
• To tie an input to all outputs, click the input number for that input.
2. Click the button to make the configuration changes or the
Take
abandon the configuration changes.
Take
FOX Matrix 320x and FOX Matrix 14400 • HTML Operation
figure 45 on the
command (step 2).
button to
Cancel
73
