Reset Button and LED

E Reset button (see
The recessed
different reset levels, press and hold the button while the switcher is running or
while you power up the switcher (see
• Hard reset (mode 1) — Restore the switcher to the default factory conditions and
return the switcher to the default firmware that shipped with the unit.
Events (mode 3) reset — Toggle events monitoring on and off.
•
• IP settings (mode 4) reset — Reset the IP functions of the switcher.
NOTE: The IP settings reset does not replace any user-installed firmware.
Absolute (mode 5) reset — Restore the switcher to the default factory conditions.
•
NOTES:

Power Supply Modules and Indicator LEDs

F Primary and Redundant AC power connectors (see
standard IEC power cords into these connectors to connect the switcher to 100 VAC to
240 VAC, 50 or 60 Hz power sources.
NOTE: For the most reliable power, connect the a power cord from the Redundant
power connector to either an uninterruptible power source or to a power source
that is completely independent from the primary power source.
G Primary and Redundant power supply indicator LEDs (see
Green — Indicates that the associated power supply is operating within normal
tolerances.
Red — Indicates that the associated power supply is operating outside the normal
tolerances or has failed (see
page 78 to replace the power supply).

Cooling Fan Assemblies

I
Primary and Redundant cooling fans (see
equipment. If a fan has failed, replace it at your earliest opportunity (see
Installing a Fan Module
figure 3
on page 8 and
button initiates four levels of matrix switcher reset. For four
Reset
Factory loaded firmware is active until it is replaced or the power is cycled.
•
• Hard reset does not clear the current configuration.
Removing and Installing a Power Supply Module
on page 80 to replace the fans).
FOX Matrix 320x and FOX Matrix 14400 • Installation
figure 4
on page 9) —
Reset Operations on page 18 for details).
figure 3
figure 3
figure 3 and figure
RESET
and figure 4) — Plug
and figure 4) —
on
4) — Cool the
Removing and
15
