Installing a Fan Module
NOTE: Captive thumbscrews must be tightened with a screwdriver after both initial
installation and subsequent replacement of a fan module.
1.
Orient the fan to be installed so that the printing on the back of the panel is rightside up.
2.
Align the flanges on the fan with the top and bottom fan guides (see
previous page).
3.
Gently slide the fan into the enclosure until the fan meets resistance.
Gently seat the fan in the backplane.
4.
5.
Use a screwdriver to tighten the top and bottom captive thumbscrews to secure the fan
in place.
Secure the row identification plate to the fan.
6.
FOX Matrix 320x and FOX Matrix 14400 • Maintenance and Modifications
figure
49, on the
81
