Software side: Adjustment for the option auto-calibration:
1. Open the menu "Setup auto-calibration". It from: "
.-
AUTO CALIBRATION
2. Select menu point "test gas composition" to set the gas composition from the
calibration gas cylinder. With the arrow keys "up/ down" an empty area can be chosen.
With the arrow keys "left/ right" the different gas compositions can be set.
3. With OK the user is able to set the gas concentrations for the different gas
compositions. First select the gas component, than press OK. A blue screen will show
up appeared. With the arrow keys the gas concentration can be set.
4. After the gas composition is set, the interval for the calibration can be set, too.
.
"
Arrow keys left/ right: With these keys the gas
composition can be set.
Arrow keys up/ down: Single positions for
the different gas compositions can be
selected.
+
