Optional AUX values are not available via Profibus.
protocol
address
AUX-values (read by up to 10 IO-modules)
370
372
374
376
378
380
382
384
386
388
390
392
394
396
398
400
402
404
406
408
410
412
414
416
418
420
422
424
426-241
442
444
446
448
MRU GmbH, D-74172 Neckarsulm
data
numb. of
register content
type
registers
FL
2
AUX-value read by IO-module 1 - Input 1
FL
2
AUX-value read by IO-module 1 - Input 2
FL
2
AUX-value read by IO-module 1 - Input 3
FL
2
AUX-value read by IO-module 1 - Input 4
FL
2
AUX-value read by IO-module 2 - Input 1
FL
2
AUX-value read by IO-module 2 - Input 2
FL
2
AUX-value read by IO-module 2 - Input 3
FL
2
AUX-value read by IO-module 2 - Input 4
FL
2
AUX-value read by IO-module 3 - Input 1
FL
2
AUX-value read by IO-module 3 - Input 2
FL
2
AUX-value read by IO-module 3 - Input 3
FL
2
AUX-value read by IO-module 3 - Input 4
FL
2
AUX-value read by IO-module 4 - Input 1
FL
2
AUX-value read by IO-module 4 - Input 2
FL
2
AUX-value read by IO-module 4 - Input 3
FL
2
AUX-value read by IO-module 4 - Input 4
FL
2
AUX-value read by IO-module 5 - Input 1
FL
2
AUX-value read by IO-module 5 - Input 2
FL
2
AUX-value read by IO-module 5 - Input 3
FL
2
AUX-value read by IO-module 5 - Input 4
FL
2
AUX-value read by IO-module 6 - Input 1
FL
2
AUX-value read by IO-module 6 - Input 2
FL
2
AUX-value read by IO-module 6 - Input 3
FL
2
AUX-value read by IO-module 6 - Input 4
FL
2
AUX-value read by IO-module 7 - Input 1
FL
2
AUX-value read by IO-module 7 - Input 2
FL
2
AUX-value read by IO-module 7 - Input 3
FL
2
AUX-value read by IO-module 7 - Input 4
FL
16
8 AUX-values read by IO-modules 8 & 9
FL
2
AUX-value read by IO-module 10 - Input 1
FL
2
AUX-value read by IO-module 10 - Input 2
FL
2
AUX-value read by IO-module 10 - Input 3
FL
2
AUX-value read by IO-module 10 - Input 4
SWG100BIO Ex. User Manual
103 / 108
