Test the alarm outputs of the IO module
Use the menu
E
/ A
XTRAS
LARM
Open the submenu
(F2).
T
EST
The following screenshot will appear. With
With the help of a multimeter, it is possible to test the different alarm outlets. The sketch below shows how to
measure the alarm outputs.
#
Calm Alarm
1
NC
NO
With the test modus for the alarm outputs of the IO module, the alarm relays at the IO
modules and the relay at the PCB mainboard can be activated.
O
C
UTPUT
ONFIGURATION
F2
all alarm outputs in the entire analyzer can be activated.
SWG100 BIOGAS User Manual
ATTENTION
MRU GmbH, D-74172 Neckarsulm
