13.
Overview of the SWG-100BIO Ex
13.1.
Scope of supply and delivery
The delivery contains the follow components:
SWG-100BIO Ex analyser, with a stainless steel case.
•
A stainless-steel thread filter for the zero gas inlet, with a G1/8 inch male thread.
•
Flow restrictor orifices for the sample gas inlets, with a G1/8 inch female thread. The
•
number of flow restrictors is depended from the number of gas sample inlets.
A fitting for the gas outlet (vent), with a G1/4 inch male thread.
•
Mounting material.
•
Optional: Flame arresters for the sample gas inlets, with a G1/4 inch male thread.
•
13.2.
Material required for the installation (not scope of supply)
Material for tubing or hosing the sample gas inlets and outlet.
For the sample gas inlets: Flexible PTFE tube or stainless steel tubing with a
•
diameter of 4/6 mm. It could be necessary to install a heated sample line on the tubes,
to protect the sample gas from freezing.
For the sample gas outlet (Vent): Flexible PTFE tube with a diameter of 8/10 mm. It
•
could be necessary to install a heated sample line on the flexible tube, to protect the
vent gas pipe for freezing.
For the condensate outlet: Flexible tube with a diameter of 4/6 mm. It could be
•
necessary to heat the condensate tube to prevent that the condensate for freezing.
Power supply lines and signal lines
Cable for power supply: Cable type: H 07 RN-F 5 G 0,75 mm²
•
Signal lines for 4...20 mA analog outputs.
•
Signal lines for Modbus RTU digital transfer.
•
SWG100 BIOGAS User Manual
MRU GmbH, D-74172 Neckarsulm
