19.2.

Check country and language

Important note:
In case the analyzer shows a language, you don't understand, you may swap the language to
English by pressing the menu key and selecting the function 'Set English language'.
Use the menu
E
The analyzer will automatically set some country-typical things like the language, the date
format, the temperature unit, the daylight-saving time function and the CSV-export settings.
19.3.

Check date and time of the instrument

The analyzer stores automatically measurement values including timestamps. Therefore, the
instruments' system clock should be set correctly.
Use the menu
E
In case the date & time is not correct, press the key F2=modify, change date & time and then
press the key F2=store.
Note:
According to the selected country (see previous chapter) the analyzer automatically switch the
daylight-saving time in spring and autumn. This function is active for most European countries.
Whenever the daylight-saving time is currently active, then you'll see a '*' in the time line of the
menu, thus 'Time *' instead of 'Time'.
19.4.

Configure sampling points

The analyzer measures at least one sample point. Optional it can measure up to 10 sample
points automatically or manually. Remote sample switching is also possible by using 4 relays
contacts connected to the 1-st I/O module
Use the F1 key in the main measurement menu
Set suction delay and measuring time for each sample point according to your needs.
Note:
You may use the function 'auto-config', which will install typical settings. Then check the
settings and modify them if needed.
MRU GmbH, D-74172 Neckarsulm
.
– G S
XTRAS ENERAL ETTINGS
– G S – D
XTRAS ENERAL ETTINGS
SWG100BIO Ex. User Manual
.
& T
ATE IME
S P C
AMPLE OINT ONFIGURATION
47 / 108
