13.5.

Operating unit: Display and keypad

14.
Operation of the keypad is intrinsically safe.
All commissioning can be carried out with the control-unit.
The operating-unit can only be operated when the cabinet door is open.
Explosion hazard
In case of system alarm, after analyser has auto-shut-off itself, the
cabinet might contain an explosive atmosphere. Any ignition source
must be avoided when opening the door.
Keypad for operation of control unit.
MRU GmbH, D-74172 Neckarsulm
Control unit
6
7
9 8
SWG100BIO Ex. User Manual
NOTE
DANGER
1
2
3
4
5
