20.4.

Main menu measurement

This menu is the root of all menus and
finished. The title bar you can see on the left the current measurement cycle status and how
long it lasts and
measurement values are
Representation during the status "measurement"
The title bar you can see on the left "measurement" and the remaining measurement duration,
and the right light blue highlighted
measured. In the middle section of the menu, the current (live) values are displayed.
Representation outside the status of "measurement"
The title bar you can see on the left "air purging" or "gas sampling SPx" and the remaining
duration of the current status. On the top right you can see the yellow highlighted
point number
measuring values are hold until it is measured again. In the middle section of the menu hold
measured values of these measurement sites are displayed.
Change the Display Zoom / Standard
Two display modes are available:
standard view mode with 6 values per page, up to 4 pages (indicating up to 24 values)
•
zoom view mode with 2 values per page, up to 6 pages (indicating up to 12 values)
•
The indication mode can be swapped with the menu key and the selection of zoom view or
standard view.
For devices with just one measuring point the switching is additional possible with the arrow
keys up / down.
Change the displayed page
Use the arrow keys left / right can be changed in both display modes the page. The new page
number is displayed in the title bar for a moment just after the successful change.
Change sampling point displayed
For analyzers with several measuring points can used the arrow keys up / down the displayed
(not measured) measuring point can be changed. In this way you can get an overview very
quickly over the last measured values for all points. In the background, the analyzer uses the
measurement cycle continues uninterrupted. However, once a measurement phase is
completed, the display automatically switches to the actual measurement location.
MRU GmbH, D-74172 Neckarsulm
will be shown automatically as soon as the self-test is
the actual sampling point
displayed.
sampling point number
SPx previously measured or that you have selected for display and their
SWG100BIO Ex. User Manual
number. In the middle section of the
SPx (x = 1 to 4) that is being
actual
sampling
