Specifications

8 Specifications

8.1 Electrical Data

8.1.1 Line Power Supply 200–240 V
Type designation
Typical shaft output (hp [kW])
Enclosure protection rating IP20 (FC 301 only)
Enclosure protection rating IP20/IP21
Enclosure protection rating IP55, IP66
Output current
Continuous (200–240 V) [A]
Intermittent (200–240 V) [A]
Continuous kVA (208 V) [kVA]
Maximum input current
8 8
Continuous (200–240 V) [A]
Intermittent (200–240 V) [A]
Additional specifications
Maximum cable cross-section
motor, brake and load sharing [mm
Maximum cable cross-section
[mm 2 ] ([AWG])
Estimated power loss at rated maximum load
3)
(hp [W])
4)
Efficiency
Table 8.1 Line Power Supply 200–240 V, PK25-P3K7
52
Instruction Manual
PK25 PK37
0.34
[0.25] [0.37]
A1
A2
A4/A5 A4/A5
1.8
2.9
0.65 0.86
1.6
2.6
2)
for line power,
2
] ([AWG])
2) for disconnect
0.028 0.039
[21]
0.94 0.94
Danfoss A/S © Rev. 09/2014 All rights reserved.
PK55 PK75 P1K1
0.5 0.75 1.0 1.5
[0.55] [0.75] [1.1]
A1 A1 A1 A1
A2 A2 A2 A2
A4/A5 A4/A5 A4/A5
2.4 3.5 4.6 6.6
3.8 5.6 7.4 10.6
1.26 1.66 2.38
2.2 3.2 4.1 5.9
3.5 5.1 6.6 9.4
4,4,4 (12,12,12)
(min. 0.2 (24))
6,4,4 (10,12,12)
0.056 0.072 0.085
[29] [42] [54] [63]
0.95 0.95 0.96
P1K5 P2K2 P3K0 P3K7
2 3 4 5
[1.5] [2.2] [3.0] [3.7]
A1 - - -
A2 A2 A3 A3
A4/A5 A4/A5 A5 A5
7.5 10.6 12.5 16.7
12.0 17.0 20.0 26.7
2.70 3.82 4.50 6.00
6.8 9.5 11.3 15.0
10.9 15.2 18.1 24.0
0.110 0.156 0.208 0.248
[82] [116] [155] [185]
0.96 0.96 0.96 0.96
