8.1.4 Line Power Supply 525–690 V (FC 302 only)
Type designation
High/Normal overload 1)
Typical shaft output (hp [kW])
Enclosure protection rating IP20
Output current
Continuous (525–550 V) [A]
Intermittent (525–550 V) [A]
Continuous (551–690 V) [A]
Intermittent (551–690 V) [A]
Continuous KVA 525 V
Continuous KVA 690 V
Maximum input current
Continuous (525–550 V) [A]
Intermittent (525–550 V) [A]
Continuous (551–690 V) [A]
Intermittent (551–690 V) [A]
Additional specifications
2)
Maximum cable cross-section for line power, motor,
2
brake and load sharing [mm ] ([AWG])
Maximum cable cross-section 2) for disconnect
[mm 2 ] ([AWG])
Estimated power loss at rated maximum load (hp
3)
[W])
Efficiency 4)
Table 8.10 A3 Enclosure, Line Power Supply 525–690 V IP20/Protected Chassis, P1K1-P7K5
MG33AP22
Instruction Manual
P1K1 P1K5
HO/NO HO/NO
1.5 [1.1] 2 [1.5]
A3 A3
2.1 2.7
3.4 4.3
1.6 2.2
2.6 3.5
1.9 2.5
1.9 2.6
1.9 2.4
3.0 3.9
1.4 2.0
2.3 3.2
0.059 [44] 0.081 [60] 0.118 [88]
0.96 0.96
