Specifications
Type designation
1)
High/Normal overload
Typical shaft output (hp [kW])
Enclosure protection rating IP20
Enclosure protection rating IP21,
IP55, IP66
Output current
Continuous (525–550 V) [A]
Intermittent (525–550 V) [A]
Continuous (551–600 V) [A]
Intermittent (551–600 V) [A]
Continuous kVA (550 V) [kVA]
Continuous kVA (575 V) [kVA]
Maximum input current
Continuous at 550 V [A]
Intermittent at 550 V [A]
Continuous at 575 V [A]
Intermittent at 575 V [A]
Additional specifications
IP20 maximum cable cross-section
for line power, brake, motor and
2
load sharing [mm ] ([AWG])
IP21, IP55, IP66 maximum cable
cross-section 2) for line power, brake
2
and load sharing [mm ] ([AWG])
IP21, IP55, IP66 maximum cable
2)
cross-section for motor
2
[mm ] ([AWG])
Maximum cable cross-section 2) for
2
disconnect [mm ] ([AWG])
Estimated power loss
at rated maximum load (hp [W])
Efficiency 4)
Table 8.8 Line Power Supply 525–600 V (FC 302 only), P11K-P30K
MG33AP22
Instruction Manual
P11K
HO NO HO
15 [11] 20 [15] 20 [15] 25 [18.5] 25 [18.5] 30 [22]
B3
B1
19 23 23
30 25 37
18 22 22
29 24 35
18.1 21.9 21.9
17.9 21.9 21.9
17.2 20.9 20.9
28 23 33
16 20 20
26 22 32
2)
10, 10, - (8, 8, -) 10, 10, - (8, 8, -)
16, 10, 10 (6, 8, 8) 16, 10, 10 (6, 8, 8)
10, 10, - (8, 8, -) 10, 10, - (8, 8, -)
0.295 0.402 0.402
3) [220] [300] [300]
0.98
Danfoss A/S © Rev. 09/2014 All rights reserved.
P15K P18K
NO HO NO
B3 B4
B1 B2
28 28 36
31 45 40
27 27 34
30 43 37
26.7 26.7 34.3
26.9 26.9 33.9
25.4 25.4 32.7
28 41 36
24 24 31
27 39 34
35, -, - (2, -, -)
35, -, - (2, -, -)
35, 25, 25 (2, 4, 4)
16, 10, 10
(6, 8, 8)
0.496 0.496 0.590
[370] [370] [440]
0.98 0.98
P22K P30K
HO NO HO
30 [22] 40 [30] 40 [30] 50 [37]
B4 B4
B2 C1
36 43 43
58 47 65
34 41 41
54 45 62
34.3 41.0 41.0
33.9 40.8 40.8
32.7 39 39
52 43 59
31 37 37
50 41 56
35, -, - (2, -, -) 35, -, - (2, -, -)
35, -, - (2, -, -) 50, -, - (1, -, -)
35, 25, 25 (2, 4, 4) 50, -, - (1, -, -)
50, 35, 35
(1, 2, 2)
0.590 0.805 0.805 0.992
[440] [600] [600] [740]
0.98 0.98
NO
54
59
52
57
51.4
51.8
49
54
47
52
8 8
59
