Commissioning

5.4.2 Commissioning via [Main Menu]

Recommended parameter settings are intended for start-
up and check-out purposes. Application settings may vary.
Enter data with power ON, but before operating the
adjustable frequency drive.
1. Press [Main Menu] on the LCP.
2. Press the navigation keys to scroll to parameter
group 0-** Operation/Display and press [OK].
1107 RPM
Main Menu
0 - ** Operation/Display
1 - ** Load/Motor
2 - ** Brakes
3 - ** Reference / Ramps
Figure 5.2 Main Menu
3. Press the navigation keys to scroll to parameter
group 0-0* Basic Settings and press [OK].
0.0%
Operation / Display
0-0 * Basic Settings
0-1 Set-up Operations
*
0-2 * LCP Display
0-3 * LCP Custom Readout
Figure 5.3 Operation/Display
4. Press the navigation keys to scroll to
0-03 Regional Settings and press [OK].
0.0%
Basic Settings
0-03 Regional Settings
[0] International
Figure 5.4 Basic Settings
MG33AP22
Instruction Manual
3.84 A 1 (1)
0.00A 1(1)
0- **
0.00A 1(1)
0-0
*
Danfoss A/S © Rev. 09/2014 All rights reserved.
5. Press the navigation keys to select [0] Interna-
tional or [1] North America as appropriate and
press [OK]. (This changes the default settings for
a number of basic parameters).
6. Press [Main Menu] on the LCP.
7. Press the navigation keys to scroll to
0-01 Language.
8. Select the language and press [OK].
9. If a jumper wire is in place between control
terminals 12 and 27, leave 5-12 Terminal 27 Digital
Input at factory default. Otherwise, select No
Operation in 5-12 Terminal 27 Digital Input. For
adjustable frequency drives with an optional
bypass, no jumper wire is required between
control terminals 12 and 27.
10. Make the application specific settings in the
following parameters:
10a 3-02 Minimum Reference
10b 3-03 Maximum Reference
10c 3-41 Ramp 1 Ramp-up Time
10d 3-42 Ramp 1 Ramp-down Time
10e 3-13 Reference Site. Linked to Hand/Auto
Local Remote.

5.4.3 Asynchronous Motor Set-up

Enter the following motor data. The information can be
found on the motor nameplate.
1. 1-20 Motor Power [kW] or 1-21 Motor Power [HP]
2. 1-22 Motor Voltage
3. 1-23 Motor Frequency
4. 1-24 Motor Current
5. 1-25 Motor Nominal Speed
When running in Flux mode, or for optimum performance
in VVC + mode, extra motor data is required to set up the
following parameters. The data can be found in the motor
data sheet (this data is typically not available on the motor
nameplate). Run a complete AMA using 1-29 Automatic
Motor Adaptation (AMA) [1] Enable Complete AMA or enter
the parameters manually. 1-36 Iron Loss Resistance (Rfe) is
always entered manually.
1. 1-30 Stator Resistance (Rs)
2. 1-31 Rotor Resistance (Rr)
3. 1-33 Stator Leakage Reactance (X1)
4. 1-34 Rotor Leakage Reactance (X2)
