Specifications
8.7.2 UL Compliance
200–240 V
Power Bussmann
(hp [kW]) 1)
Type RK1
0.34–0.5 KTN-R-05
[0.25–0.37]
0.75–1.5 KTN-R-10
[0.55–1.1]
2 [1.5] KTN-R-15
3 [2.2] KTN-R-20
4 [3.0] KTN-R-25
5 [3.7] KTN-R-30
7.5 [5.5] KTN-R-50
10 [7.5] KTN-R-60
15 [11] KTN-R-80
20–25 [15–18.5] KTN-R-125
30 [22] KTN-R-150
40 [30] KTN-R-200
50 [37] KTN-R-250
Table 8.17 200–240 V, Enclosure Types A, B and C
Power SIBA
(hp [kW]) Type RK1
0.34–0.5 5017906-005
[0.25–0.37]
0.75–1.5 5017906-010
[0.55–1.1]
2 [1.5] 5017906-016
3 [2.2] 5017906-020
4 [3.0] 5017906-025
5 [3.7] 5012406-032
7.5 [5.5] 5014006-050
10 [7.5] 5014006-063
15 [11] 5014006-080
20–25 [15–18.5] 2028220-125
30 [22] 2028220-150
40 [30] 2028220-200
50 [37] 2028220-250
Table 8.18 200–240 V, Enclosure Types A, B and C
1) KTS fuses from Bussmann may substitute KTN for 240 V adjustable frequency drives.
2) FWH fuses from Bussmann may substitute FWX for 240 V adjustable frequency drives.
3) A6KR fuses from FERRAZ SHAWMUT may substitute A2KR for 240 V adjustable frequency drives.
4) A50X fuses from FERRAZ SHAWMUT may substitute A25X for 240 V adjustable frequency drives.
MG33AP22
Instruction Manual
Recommended maximum fuse
Bussmann Bussmann
Type J Type T
JKS-05 JJN-05
JKS-10 JJN-10
JKS-15 JJN-15
JKS-20 JJN-20
JKS-25 JJN-25
JKS-30 JJN-30
KS-50 JJN-50
JKS-60 JJN-60
JKS-80 JJN-80
JKS-125 JJN-125
JKS-150 JJN-150
JKS-200 JJN-200
JKS-250 JJN-250
Recommended maximum fuse
Ferraz- Ferraz-
Littelfuse
Shawmut
Shawmut
Type RK1
Type CC Type RK1
KLN-R-05 ATM-R-05 A2K-05-R
KLN-R-10 ATM-R-10 A2K-10-R
KLN-R-15 ATM-R-15 A2K-15-R
KLN-R-20 ATM-R-20 A2K-20-R
KLN-R-25 ATM-R-25 A2K-25-R
KLN-R-30 ATM-R-30 A2K-30-R
KLN-R-50 - A2K-50-R
KLN-R-60 - A2K-60-R
KLN-R-80 - A2K-80-R
KLN-R-125 - A2K-125-R
KLN-R-150 - A2K-150-R
KLN-R-200 - A2K-200-R
KLN-R-250 - A2K-250-R
Danfoss A/S © Rev. 09/2014 All rights reserved.
Bussmann Bussmann
Type CC Type CC
FNQ-R-5 KTK-R-5
FNQ-R-10 KTK-R-10
FNQ-R-15 KTK-R-15
FNQ-R-20 KTK-R-20
FNQ-R-25 KTK-R-25
FNQ-R-30 KTK-R-30
- -
- -
- -
- -
- -
- -
- -
Bussmann Littelfuse
2) JFHR2
Type JFHR2
3)
FWX-5 -
FWX-10 -
FWX-15 -
FWX-20 -
FWX-25 -
FWX-30 -
FWX-50 -
FWX-60 -
FWX-80 -
FWX-125 -
FWX-150 L25S-150
FWX-200 L25S-200
FWX-250 L25S-250
Bussmann
Type CC
LP-CC-5
LP-CC-10
LP-CC-15
LP-CC-20
LP-CC-25
LP-CC-30
-
-
-
-
-
-
-
Ferraz- Ferraz-
Shawmut
Shawmut
JFHR2 4) J
- HSJ-6
- HSJ-10
- HSJ-15
- HSJ-20
- HSJ-25
- HSJ-30
- HSJ-50
- HSJ-60
- HSJ-80
- HSJ-125
A25X-150 HSJ-150
A25X-200 HSJ-200
A25X-250 HSJ-250
