Specifications
525–600 V
Enclosure
A2
A3
A5
B1
B2
B3
B4
8 8
C1
C2
C3
C4
Table 8.15 525–600 V, Enclosure Types A, B and C
525–690 V
Enclosure
A3
B2/B4
B4/C2
C2/C3
C2
Table 8.16 525–690 V, Enclosure Types A, B and C
72
Power (hp [kW]) Recommended
fuse size
1–5 [0.75–4.0] gG-10
7.5–10 [5.5–7.5] gG-10 (7.5 [5.5])
gG-16 (10 [7.5])
1–10 [0.75–7.5] gG-10 (0.75–5.5)
gG-16 (7.5)
15–24 [11–18] gG-25 (15 [11])
gG-32 (20 [15])
gG-40 (25 [18.5])
30–40 [22–30] gG-50 (30 [22])
gG-63 (40 [30])
15–20 [11–15] gG-25 (11)
gG-32 (15)
25–40 [18.5–30] gG-40 (18.5)
gG-50 (22)
gG-63 (30)
50–75 [37–55] gG-63 (50 [37])
gG-100 (60 [45])
aR-160 (75 [55])
100 [75] aR-200 (75)
50–60 [37-45] gG-63 (37)
gG-100 (45)
75–100 [55–75] aR-160 (55)
aR-200 (75)
Power (hp [kW]) Recommended
fuse size
1.5 [1.1] gG-6
2 [1.5] gG-6
3 [2.2] gG-6
4 [3] gG-10
5 [4] gG-10
7.5 [5.5] gG-16
10 [7.5] gG-16
15 [11] gG-25 (11)
20 [15] gG-32 (15)
24 [18] gG-32 (18)
30 [22] gG-40 (22)
40 [30] gG-63 (30)
50 [37] gG-63 (37)
60 [45] gG-80 (45)
75 [55] gG-100 (55)
100 [75] gG-125 (75)
Danfoss A/S © Rev. 09/2014 All rights reserved.
Instruction Manual
Recommended
maximum fuse
gG-25
gG-32
gG-32
gG-80
gG-100
gG-63
gG-125
gG-160 (50–60 [37–45])
aR-250 (75 [55])
aR-250
gG-150
aR-250
Recommended
maximum fuse
gG-25
gG-25
gG-25
gG-25
gG-25
gG-25
gG-25
gG-63
gG-80 (30)
gG-100 (37)
gG-125 (45)
gG-160 (55–75)
Recommended circuit Maximum trip level
breaker
Moeller
PKZM0-25
PKZM0-25
PKZM0-25
PKZM4-63
NZMB1-A100
PKZM4-50
NZMB1-A100
NZMB2-A200
NZMB2-A250
NZMB2-A200
NZMB2-A250
Recommended circuit Maximum trip level
breaker
Moeller
PKZM0-16
-
-
-
-
[A]
25
25
25
63
100
50
100
160
250
150
250
[A]
16
-
-
-
-
MG33AP22
