Quick Guide

1.2.5 Disposal Instructions

Equipment containing electrical components
may not be disposed of together with domestic
waste.
It must be separately collected with electrical
and electronic waste according to local and
currently valid legislation.
Table 1.3

1.3 Installation

1.3.1 Before Starting Repair Work

1. Disconnect FC101 from line power (and external
DC supply, if present.)
2. Wait as long as indicated in the table below for
the DC link to discharge:

1.3.2 Side-by-Side Installation

The Adjustable frequency drive can be mounted side-by-side and requires the clearance above and below for cooling.
Frame IP class
H1 IP20 0.25–1.5 kW/0.33–2 HP
H2 IP20
H3 IP20
H4 IP20 5.5–7.5 kW/7.5–10 HP
H5 IP20
H6 IP20 15–18.5 Kw/20–25 HP
H7 IP20 22–30 kW/30–40 HP
H8 IP20 37–45 kW/50–60 HP
H9 IP20
H10 IP20
Table 1.5
NOTE!
With IP21/Nema Type1 option kit mounted, a distance of 2 in [50 mm] between the units is required.
VLT HVAC Basic Drive Quick Guide
3 x 200–240 V 3 x 380–480 V
0.37–1.5 kW/0.5–2 HP
2.2 kW/3 HP 2.2–4 kW/3–5.4 HP
3.7 kW/5 HP 5.5–7.5 kW/7.5–10 HP
11–15 kW/15–20 HP
11 kW/15 HP 18.5–22 kW/25–30 HP
30–45 kW/40–60 HP
55–75 kW/100–120 HP
90 kW/125 HP
®
MG18A322 - VLT is a registered Danfoss trademark
Voltage (V) Power range (HP/kW)
3 x 200 0.34–5 [0.25–3.7]
3 x 200 7.5–60 [5.5–45]
3 x 400 0.5–10 [0.37–7.5]
3 x 400 15–125 [11–90]
3 x 600 3–10 [2.2–7.5]
3 x 600 15–125 [11–90]
Table 1.4
3. Remove motor cable
Power
3 x 525–600 V
22–30 kW/30–40 HP
45–55 kW/60–100 HP
75–90 kW/120–125 HP
2.2–7.5 kW/3–10 HP
11–15 kW/15–20 HP
1
Min. waiting time
(minutes)
4
15
4
15
4
15
Clearance above/
below (mm/inch)
100/4
100/4
100/4
100/4
100/4
200/7.9
200/7.9
225/8.9
100/4
200/7.9
1-3
1
