Quick Guide
H8 Frame
IP20 380-480 V 125 hp [90 kW]
IP20 200–240 V 50–60 hp [37–45 kW]
IP20 525–600 V 100–125 hp [75–90 kW]
1
2
3
Figure 1.6
1 Line
2 Relays
3 Ground
4 Motor
Table 1.15
VLT HVAC Basic Drive Quick Guide
4
®
MG18A322 - VLT is a registered Danfoss trademark
H9 Frame
IP20 600 V 3–10 hp [2.2–7.5 kW]
Figure 1.7
Figure 1.8
1 1
1-9
