Quick Guide
Minimum cross-section to control terminals
*See tables for line power supply for more information
Digital inputs:
Programmable digital inputs
Terminal number
Logic
Voltage level
Voltage level, logic '0' PNP
Voltage level, logic '1' PNP
Voltage level, logic '0' NPN
Voltage level, logic '1' NPN
Maximum voltage on input
Input resistance, R
i
Digital input 29 as thermistor input
Analog inputs
Number of analog inputs
Terminal number
Terminal 53 mode
Terminal 54 mode
Voltage level
Input resistance, R
i
Max. voltage
Current level
Input resistance, R
i
Max. current
Analog output
Number of programmable analog outputs
Terminal number
Current range at analog output
Max. load to common at analog output
Max. voltage at analog output
Accuracy on analog output
Resolution on analog output
1) Terminal 42 and 45 can also be programmed as digital outputs.
Digital output
Number of digital outputs
Terminal number
Voltage level at digital output
Max. output current at digital output
Max. load at digital output
1) Terminals 42 and 45 can also be programmed as analog output.
Control card, RS485 serial communication
Terminal number
Terminal number
Control card, 24 V DC output:
Terminal number
Max. load enclosure frame H1-H8, I2-I8
VLT HVAC Basic Drive Quick Guide
®
MG18A322 - VLT is a registered Danfoss trademark
0.05 mm
18, 19, 27, 29
PNP or NPN
Approx. 4 k
Fault: > 2.9 kΩ and no fault: < 800Ω
Parameter 6-19: 1 = voltage, 0 = current
Parameter 6-29: 1 = voltage, 0= current
approx. 10 kΩ
0/4 to 20 mA (scalable)
Max. error: 0.4% of full scale
68 (P, TX+, RX+), 69 (N, TX-, RX-)
61 Common for terminals 68 and 69
1 1
2
/30 AWG
4
0-24 V DC
< 5 V DC
> 10 V DC
> 19 V DC
< 14 V DC
28 V DC
2
53, 54
0–10 V
20 V
<500Ω
29 mA
2
1)
42, 45
0/4–20 mA
500 Ω
17 V
10 bit
2
42, 45 1)
17 V
20 mA
1 kΩ
12
80 mA
1-43
