Quick Guide
1 1
The FC101 Start-up Wizard for Open-loop Applications
No & Name
0-03 Regional Settings
0-06 Grid Type
1-20 Motor Power
1-22 Motor Voltage
1-23 Motor Frequency
1-24 Motor Current
1-25 Motor Nominal
Speed
4-12 Motor Speed Low
Limit [Hz]
4-14 Motor Speed High
Limit [Hz]
3-41 Ramp 1 Ramp Up
Time
3-42 Ramp 1 Ramp
Down Time
1-73 Flying Start
6-19 Terminal 53 mode
6-10 Terminal 53 Low
Voltage
6-11 Terminal 53 High
Voltage
6-12 Terminal 53 Low
Current
1-22
VLT HVAC Basic Drive Quick Guide
Range
[0] International
[1] US
[0] 200–240 V/50 Hz/IT grid
[1] 200–240 V/50 Hz/Delta
[2] 200–240 V/50 Hz
[10] 380–440 V/50 Hz/IT grid
[11] 380–440 V/50 Hz/Delta
[12] 380–440 V/50 Hz
[20] 440–480 V/50 Hz/IT grid
[21] 440–480 V/50 Hz/Delta
[22] 440–480 V/50 Hz
[30] 525–600 V/50 Hz/IT grid
[31] 525–600 V/50 Hz/Delta
[32] 525–600 V/50 Hz
[100] 200–240 V/60 Hz/IT grid
[101] 200–240 V/60 Hz/Delta
[102] 200–240 V/60 Hz
[110] 380–440 V/60 Hz/IT grid
[111] 380–440 V/60 Hz/Delta
[112] 380–440 V/60 Hz
[120] 440–480 V/60 Hz/IT grid
[121] 440–480 V/60 Hz/Delta
[122] 440–480 V/60 Hz
[130] 525–600 V/60 Hz/IT grid
[131] 525–600 V/60 Hz/Delta
[132] 525–600 V/60 Hz
0.12–110 kW/0.16–150 hp
50.0–1,000.0 V
20.0–400.0 Hz
0.01–10,000.00 A
100.0–9,999.0 RPM
0.0–400 Hz
0.0–400 Hz
0.05–3,600.0 s
0.05–3,600.0 s
[0] Disabled
[1] Enabled
[0] Current
[1] Voltage
0–10 V
0–10 V
0-20 mA
MG18A322 - VLT
Default Function
0
Size related Select operating mode for restart upon
reconnection of the drive to AC line voltage after
power-down
Size related Enter motor power from nameplate data
Size related Enter motor voltage from nameplate data
Size related Enter motor frequency from nameplate data
Size related Enter motor current from nameplate data
Size related Enter motor nominal speed from nameplate data
0 Hz Enter the minimum limit for low speed
65 Hz Enter the maximum limit for high speed
Size related Ramp-up time from 0 to rated 1-23 Motor
Frequency
Size related Ramp-down time from rated 1-23 Motor Frequency
to 0
0 Select Enable to enable the Adjustable frequency
drive to catch a spinning motor, i.e., fan
applications
1 Select if terminal 53 is used for current or voltage
input.
0.07 V Enter the voltage that corresponds to the low
reference value.
10 V Enter the voltage that corresponds to the high
reference value.
4 Enter the current that corresponds to the low
reference value.
®
