15-3* Fault Log
15-30 Fault Log:
Error Code 0–255, * 0
15-4* Drive Identification
15-40 FC Type
15-41 Power Section
15-42 Voltage
15-43 Software Version
15-44 OrderedTypeCode
15-46 Adjustable Frequency
Drive
Ordering No
15-47 Power Card Ordering No
15-48 LCP ID No
15-49 Software ID Control Card
15-50 Software ID Power Card
15-51 Adjustable Frequency
Drive Serial Number
15-53 Power Card Serial Number
16-** Data Readouts
16-0* General Status
16-00 Control Word
0–65535, * 0
16-01 Reference [Unit]
-4,999.000–4,999.000, * 0.000
16-02 Reference
% -200.0–200.0, * 0.0
16-03 Status Word
0–65535, * 0
16-05 Main Actual Value [%]
-200.00–200.00, * 0.00
16-09 Custom Readout
0.00–9,999.00, * 0.00
16-1* Motor Status
16-10 Power [kW]
0.000–4.294, 967.500, *0.000
16-11 Power [HP]
0.000–2.294, 967.500 *0.000
16-3* Drive Status
Table 1.31
1-32
VLT HVAC Basic Drive Quick Guide
Parameter Overview
16-30 DC Link Voltage
0–65535, * 0
16-34 Heatsink Temp.
0–255, * 0
16-35 Inverter Thermal
0–255%, * 0
16-36 Inv. Nom. Current
0.00–655.35, * 0.00
16-37 Inv. Max. Current
0.00 - 655.35
16-38 SL Controller State
0–255, * 0
16-5* Ref. and Feedb.
16-50 External Reference
-200.0–200.0%, * 0.0
16-52 Feedback
-4,999.000–4,999.000, * 0.000
16-6* Inputs and Outputs
16-60 Digital input
0–65535, * 0
16-61 Terminal 53 Setting
*[0] Current mode
[1] Voltage mode
16-62 Analog Input 53
0.00–10.00, * 1.00
16-63 Terminal 54 Setting
*[0] Current mode
[1] Voltage mode
16-64 Analog Input 54
0.00–20.00, * 1.00
16-65 Analog Output 42 [mA]
0.00–20.00, * 0.00
16-61 Digital Output
16-72 Counter A
-32768–32767, * 0
16-73 Counter B
-32768–32767, * 0
16-79 Analog output 45
20 - 20mA, * 0
16-8* Serial communication bus /
FC Port
16-86 FC Port REF 1
-32768–32767, * 0
16-9* Diagnosis Readouts
16-90 Alarm Word
0–0xFFFFFFFFUL, * 0
®
MG18A322 - VLT is a registered Danfoss trademark
16-91 Alarm Word 2
0–0xFFFFFFFFUL, * 0
16-92 Warning Word
0–0x7FFFFFFFUL, * 0
16-93 Warning Word 2
0–0x7FFFFFFFUL, * 0
16-94 Ext. Status Word
0–0x7FFFFFFFUL, * 0
16-95 Ext. Status Word 2
0–0x7FFFFFFFUL, * 0
18-**Extended Motor Data
18-1* Firemode Log
18-10 Firemode log: Event
0–255, *0
20-** FC Closed-loop
20-0* Feedback
20-00 Feedback 1 Source
*[0] No function
[1] Analog in 53
[2] Analog in 54
[100] Bus Feedback 1
20-01 Feedback 1 Conversion
*[0] Linear
[1] Square root
20-8* PI Basic Setting
20-81 Process PI Normal/ Inverse
Control
*[0] Normal
[1] Inverse
20-83 Process PI Start Speed [Hz]
0.0–200.0, * 0.0
20-84 On Reference Bandwidth
0–200%, * 5
20-9* PI Controller
20-91 PI Anti Windup
[0] Off
*[1] On
20-93 PI Proportional Gain
0.00 - 10.00, * 0.01
20-94 PI Integral Time
0.10–9,999.00s, * 9,999.00
20-97 Process PI Feed Forward
Factor
0–400%, * 0
22-** Appl. functions
22-4* Sleep mode
22-40 Minimum Run Time
0–600 s, * 10
22-41 Minimum Sleep Time
0–600 s, * 10
22-43 Wake-Up Speed [Hz]
0.0–400.0, * 100.0
22-44 Wake-Up Ref./FB difference
0–100%, * 10
22-45 Setpoint Boost
-100 - 100%, * 0
22-46 Maximum Boost Time
0–600 s, * 60
22-47 Sleep Speed [Hz]
0.0–400.0, * 0.0
22-6* Broken Belt Detection
22-60 Broken Belt Detection
*[0] Off
[1] Warning
[2] Trip
22-61 Broken Belt Torque
5–100%, * 10
22-62 Broken Belt Delay
0–600 s, * 10
24-** Appl. functions 2
24-0* Fire mode
24-00 Fire Mode Function
*[0] Disabled
[1] Enabled Run Forward
[2] Enabled Run Reverse
[3] Enable-Coast
[4] Enabled - Run Fwd/Rev
24-05 Fire Mode Preset Reference
-100–100%, * 0
24-09 Fire Mode Alarm Handling
*[1] Trip, Critical Alarms
[2] Trip, All Alarms/Test
24-1* Drive Bypass
24-10 Drive Bypass Function
*[0] Disabled
[2] Enabled (Fire Mode only)
24-11 Bypass Delay Timer
0–600 s, * 0
