Quick Guide
1 1
H6 Frame
IP20 380–480 V 40–60 hp [30–45 kW]
IP20 200–240 V 20–25 hp [15–18.5 kW]
IP20 525–600 V 30–40 hp [22–30 kW|
95
1
Figure 1.4
1 Line
2 Motor
3 Ground
4 Relays
Table 1.13
1-8
VLT HVAC Basic Drive Quick Guide
99
4
2 3
MG18A322 - VLT
H7 Frame
IP20 380–480 V 75–100 hp [55–75 kW]
IP20 200–240 V 30–40 hp [22–30 kW]
IP20 525–600 V 60–75 hp [45–55 kW]
1 2
Figure 1.5
1 Line
2 Relays
3 Ground
4 Motor
Table 1.14
®
is a registered Danfoss trademark
