Quick Guide
1 1
Motor Set-up
The Quick Menu Motor Set-up guides you through the
needed motor parameters.
No & Name
0-03 Regional
Settings
0-06 Grid
Type
1-20 Motor
power
1-22 Motor
Voltage
1-23 Motor
Frequency
1-24 Motor
Current
1-25 Motor
Nominal
Speed
4-12 Motor
Speed Low
Limit [Hz]
4-14 Motor
Speed High
Limit [Hz]
3-41 Ramp 1
Ramp Up
Time
3-42 Ramp 1
Ramp Down
Time
1-26
VLT HVAC Basic Drive Quick Guide
Range Default Function
[0] Interna- 0
tional
[1] US
[0]-[132] Please Size selected Select operating
see start-up mode for restart
wizard for upon
open-loop reconnection of
application the Adjustable
frequency drive
to AC line
voltage after
power-down
0.12–110 kW/ Size related Enter motor
0.16–150 HP power from
nameplate data
50.0–1,000.0 V Size related Enter motor
voltage from
nameplate data
20.0–400.0 Hz Size related Enter motor
frequency from
nameplate data
0.01–10,000.00 Size related Enter motor
A current from
nameplate data
100.0–9,999.0 Size related Enter motor
RPM nominal speed
from nameplate
data
0.0–400 Hz 0.0 Hz Enter the
minimum limit
for low speed
0–400 Hz 65 Enter the
maximum limit
for high speed
0.05–3,600.0 s Size related Ramp-up time
from 0 to rated
motor frequency
1-23 Motor
Frequency
0.05–3,600.0 s Size related Ramp-down time
from rated motor
frequency
1-23 Motor
Frequency to 0
MG18A322 - VLT
No & Name Range
1-73 Flying [0] Disabled
Start [1] Enabled
Table 1.25
Changes Made
Changes Made lists all parameters changed since factory
setting. Only the changed parameters in current edit-setup
are listed in changes made.
If the parameter's value is changed back to the factory
setting value from another different value, the parameter
will NOT be listed in Changes Made.
1. Press [Menu] key to enter the Quick Menu until
indicator in display is placed above Quick Menu.
▲ ▼
2.
Press [ ] [
closed-loop set-up, motor set-up or changes
made, then press [OK].
▲ ▼
3.
Press [ ] [
in the Quick Menu.
4. Press [OK] to select a parameter.
▲ ▼
5.
Press [ ] [
setting.
6. Press [OK] to accept the change.
7. Press either [Back] twice to enter "Status", or
press [Menu] once to enter "Main Menu".
The Main Menu accesses all parameters.
1. Press [Menu] key until indicator in display is
placed above "Main Menu".
▲ ▼
2.
Use [ ] [ ] to browse through the parameter
groups.
3. Press [OK] to select a parameter group.
▲ ▼
4.
Use [ ] [ ] to browse through the parameters in
the specific group.
5. Press [OK] to select the parameter.
▲ ▼
6.
Use [ ] [ ] to set/change the parameter value.
®
is a registered Danfoss trademark
Default Function
0 Select Enable to
enable the
Adjustable
frequency drive
to catch a
spinning motor
] to select either FC101 wizard,
] to browse through the parameters
] to change the value of a parameter
