5020 Data Collection PC User's Manualdfdf
Understanding the Notification Tray Icons (continued)
Icon
2-6
dfdf
Description
Center Modifier This icon appears when you press
•
When pressed and released, the icon appears. After you press the next key,
the icon disappears.
•
When pressed and held for more than 1 second, the icon turns on, and the
5020 beeps and is locked in Center Modifier mode. Following key presses
display their center modifier characters. When the 5020 is locked in Center
Modifier mode, pressing and holding the center modifier key for more than
1 second takes the 5020 out of Center Modifier mode and the icon
disappears.
Right Modifier This icon appears when you press
•
When pressed and released, the icon appears. After you press the next key,
the icon disappears.
•
When pressed and held for more than 1 second, the icon turns on, and the
5020 beeps and is locked in Right Modifier mode. Following key presses
display their right modifier characters. When the 5020 is locked in Right
Modifier mode, pressing and holding the right modifier key for more than
1 second takes the 5020 out of Right Modifier mode and the icon
disappears.
Full Charge The main battery pack is at or near full charge. Battery is
charged 75% to 100% of capacity.
Half Charge The main battery pack is in the middle of the battery charge
range.
Low Charge The main battery pack is at a critically low level and needs to be
charged.
Unknown Main Battery Status Indicates the main battery pack is charging or
the status is not known.
Radio connect If the Radio Connect icon is not displayed, the 5020 is not
connected to an access point. You may be out of range of an access point or the
5020 may not be configured correctly. If the Connect icon blinks, the 5020 is
trying to connect to an access point. You may be out of range of an access
point, you may be about to go out of range of an access point, or the access
point may have recently been turned off.
.
.
