  • Page 1: Mobile Computer

    70 Series Mobile Computer CK70, CK70NI, CK71, CK71NI, CN70, CN70NI, CN70e, CN70eNI User Manual...
  • Page 2 Intermec Technologies Corporation. Information and specifications contained in this document are subject to change without prior notice and do not represent a commitment on the part of Intermec Technologies Corporation. © 2011 - 2012 by Intermec Technologies Corporation. All rights reserved.
  • Page 3 Revised information on ScanNGo bar codes. 12/2011 Added information on: • the flashlight feature. • the Carrier Selection application. Revised information on: • the Intermec Settings menus. • upgrading the system software and the operating system. • GPS procedures. • ScanNGo bar codes. 06/2011...
  • Page 4 70 Series Mobile Computer User Manual...

  • Page 5: Table Of Contents

    About the Intermec Dashboard Button ........
  • Page 6 Install a MicroSD Card in a CK70 or CK71 ....... .
  • Page 7 About the Structure of Intermec Settings ........
  • Page 8 About the Intermec Dashboard ........
  • Page 9 CK70 Physical Dimensions ........
  • Page 10 CK70 Keypads and Keystrokes ........

  • Page 11: Before You Begin

    Global Services and Support Warranty Information To understand the warranty for your Intermec product, visit the Intermec website at www.intermec.com and click Support > Returns and Repairs > Warranty.

  • Page 12: Send Feedback

    Before You Begin Visit the Intermec technical knowledge base (Knowledge Central) at www.intermec.com and click Support > Knowledge Central to review technical information or to request technical support for your Intermec product. Send Feedback Your feedback is crucial to the continual improvement of our documentation.

  • Page 13: Patent Information

    Before You Begin To download documents 1 Visit the Intermec website at www.intermec.com. 2 Click the Products tab. 3 Using the Products menu, navigate to your product page. For example, to find the CN70 computer product page, click Computers > Handheld Computers > CN70.
  • Page 14 Before You Begin 6152370; 6155490; 6158661; 6164542; 6164545; 6173893; 6195053; 6234393; 6234395; 6244512; 6249008; 6328214; 6330975; 6345765; 6356949; 6367699; 6375075; 6375076; 6375344; 6431451; 6435411; 6484944; 6488209; 6497368; 6532152; 6538413; 6539422; 6621942; 6641046; 6681994; 6687403; 6688523; 6732930 There may be other U.S. and foreign patents pending. 70 Series Mobile Computer User Manual...

  • Page 15: About The Computer Features

    About the Computer Features This chapter introduces the 70 Series Mobile Computers with Windows® Embedded Handheld operating system. Use this chapter to learn about the basic features and functions of each computer, as well as the available accessories for it.

  • Page 16: About The 70 Series Mobile Computers

    70 Series unless information is specific to a particular model of computer. In most of the user manual, pictures of the CN70 and CK70 represent the four models of the 70 Series computers. CN70 Front View...
  • Page 17 Chapter 1 — About the Computer Features CN70 Back View Imager Camera Speaker port IrDa port Battery CK70 and CK71 Front View Cell phone speaker Good read LED Notification LED Battery status LED Scan button On/off button Microphone 70 Series Mobile Computer User Manual...

  • Page 18: What's New In This Release

    This version of the user manual supports firmware version 1.50 and includes information about these new features: • Intermec CloneNGo is a peer-to-peer device management application that ships on every computer and simplifies the process of configuring multiple computers. For more information, see “Manage the Computer Using CloneNGo”...

  • Page 19: Overview Of 70 Series Features

    Chapter 1 — About the Computer Features Overview of 70 Series Features The 70 Series includes these standard features: • EA30 area imager that can read bar codes and capture images • (CK71 only) Choice of EA30, EX25, or EV12 imagers •...

  • Page 20: About The Status Leds

    Chapter 1 — About the Computer Features About the Status LEDs Use the following illustrations and table to understand the status LEDs on your computer. All six status LEDS are not available on every 70 Series computer. For example, the QWERTY versions of the CN70 and CN70e do not have a Green key status LED.
  • Page 21 Chapter 1 — About the Computer Features Location of the CK70 and CK71 Status LEDs Good Read and Ready-to-Work Notification LED status LED Orange key Battery status LED status LED Green key status LED Shift key status LED (CK70 alphanumeric...

  • Page 22: 70 Series Accessories

    The Orange function key is enabled. Shift The Shift key is enabled. 70 Series Accessories The 70 Series computer ships with a battery. All other accessories are sold and ordered separately. For help, contact your local Intermec sales representative. 70 Series Accessories Accessory Description...
  • Page 23 Ethernet network. Handstrap Replacement Kit You can order and install a replacement handstrap for the CN70, CN70e, and CK70/CK71. Each kit contains 5 handstraps. Holster Use the holster to store the computer when you need your hands free.

  • Page 24: About Language Provisioning

    The computers use these rechargeable Lithium-ion battery pack as the main power source: • 3.7 V, 4000 mAH (14.8 Wh) battery for the CN70 and CN70e • 3.7 V, 5200 mAH (19.2 Wh) battery for the CK70 and CK71 70 Series Mobile Computer User Manual...

  • Page 25: Charge The Battery

    Up to 6 hours DX1, DX2, or DX4 dock Up to 6 hours CN70, CN70e, CK70, and CK71 Vehicle Power Adapter Up to 6 hours Change the Battery If your battery power is low, you need to either charge the battery in the computer, or replace it with a charged battery.
  • Page 26 Chapter 1 — About the Computer Features Detach the Handstrap From a CK70 or CK71 4 Make sure the computer is in hibernate mode and the screen is off. 5 Remove the battery. • On the CN70 or CN70e, push the battery release toward the bottom of the computer until the battery releases and then lift it away from the computer.

  • Page 27: About Battery Status

    Chapter 1 — About the Computer Features • On the CK70 or CK71, push the battery release toward the top of the computer until the battery releases and then lift it away from the computer. 6 Insert the top end of a fully charged battery into the computer, and press down firmly on the bottom of the battery.
  • Page 28 Chapter 1 — About the Computer Features Battery Icon Status Battery is critically low. You need to replace the battery now. Battery is charging. The battery is not installed. You can also use the battery status LED to see the charging status of your battery.

  • Page 29: About Battery Life And Conservation

    Chapter 1 — About the Computer Features About Battery Life and Conservation Batteries that are stored outside the computer for long periods of time slowly discharge. Intermec recommends storing the battery in a charger to maintain battery performance. Battery Conservation Tips...

  • Page 30: About The Keypad

    By default, the keypad backlight is enabled in low light conditions. You can disable the keypad backlight to conserve power. Use Intermec Settings to configure the backlight. For help, see “Use Intermec Settings on the Computer” on page CN70 QWERTY Keypad &...
  • Page 31 Chapter 1 — About the Computer Features CN70 Numeric Keypad Enter CN70e QWERTY Numeric Keypad 70 Series Mobile Computer User Manual...
  • Page 32 Chapter 1 — About the Computer Features CN70e Calculator-Style Numeric Keypad CN70e Numeric Keypad 70 Series Mobile Computer User Manual...
  • Page 33 Chapter 1 — About the Computer Features The CK70 comes with either a large alpha or an alphanumeric keypad. The CK71 comes with either a numeric function keypad or an alphanumeric keypad. The computer has an ambient light sensor that detects low light and turns on the keypad backlight.
  • Page 34 Chapter 1 — About the Computer Features CK70 Alphanumeric Keypad Send Insert Delete Enter Ctrl Space 70 Series Mobile Computer User Manual...
  • Page 35 Chapter 1 — About the Computer Features CK71 Numeric Function Keypad View Insert SysRq Fld- Fld+ Return View Enter Exit PrvScr Roll NxtScr Delete Roll Clear Reset Space Home Attn Return Enter F10 F11 F12 Ctrl 70 Series Mobile Computer User Manual...
  • Page 36 Chapter 1 — About the Computer Features CK71 Alphanumeric Keypad Reset View Exit PrvScr Roll NxtScr Insert Roll Delete Clear Fld- Fld+ Autolog Return Enter EEOF Ctrl Space Attn Erase Find FldMk Home Keypd Menu Remove NewLn SysRq Mode Print Select 70 Series Mobile Computer User Manual...

  • Page 37: Enter Characters On The Qwerty Keypad

    Chapter 1 — About the Computer Features Enter Characters on the QWERTY Keypad You need to use the orange modifier key and the Shift key access all characters and functions on the QWERTY keypad. To type a character: • Press the key for that character. To type a character or access a function on the overlay: •...

  • Page 38: Enter Characters On The Ck70 And Ck71 Keypads

    Note: If uppercase letters are enabled and you unlock the green modifier key, you may need to press to type lowercase letters. Enter Characters on the CK70 and CK71 Keypads You need to use the orange modifier key , the green modifier key...

  • Page 39: About The Power Button

    (the button outlined in bold) occurs after the timeout. The Intermec Power Options Default Screen Note: The Real Time Clock (RTC) persists through all of the power options as long as it receives power from the Real Time Clock battery.

  • Page 40: About The Intermec Dashboard Button

    You must press Power or apply external power to restart the computer. The Intermec Power Options screen is customizable. You can use Intermec Settings to determine which options are available to end users, the timeout until the default choice is selected, the default action if no option is selected, or to disable the Power Options screen.

  • Page 41: Configure The Screen Backlight

    3 Select the screen power off settings for when the computer is on battery power or external power. Configure the Screen Brightness You can configure the screen brightness using Intermec Settings or from the Start menu. 1 Tap Start > Settings > System > Backlight.

  • Page 42: About The Imager

    Chapter 1 — About the Computer Features You can adjust the volume settings using Intermec Settings or the horizontal scroll menu. 1 Tap the Volume icon at the top of the screen, and then tap the volume icon on the horizontal scroll menu.

  • Page 43: Read Bar Codes

    “Connect to a Tethered Scanner” on page 89, respectively. 1 Enable only the bar code symbologies that you need. 2 Use Intermec Settings to select the predefined imager mode that best suits your environment: Predefined Mode For Scanning Only 1D labels.

  • Page 44: Insert A Microsd Card

    Chapter 1 — About the Computer Features Scanning With the EA30 Imager 5 Use the laser pointer as a guide and aim toward the middle of the bar code. Make sure that the illumination beam or frame covers the bar code you are trying to decode. When the computer successfully reads a bar code label, you hear a high beep, and the Good Read LED turns on briefly.
  • Page 45 Chapter 1 — About the Computer Features 3 Remove the two Phillips screws and open the card access door. 4 Slide the SIM card door to the left to unlock it and open the door. 70 Series Mobile Computer User Manual...
  • Page 46 Chapter 1 — About the Computer Features 5 Slide the microSD card door towards the top of the computer to unlock it and open the door. 6 Slide the microSD card into place. 7 Close the microSD card door and slide it towards the bottom of the computer to lock it in place.

  • Page 47: Install A Microsd Card In A Ck70 Or Ck71

    11 Attach the handstrap. 12 Press the Power button. The computer cold boots. Install a MicroSD Card in a CK70 or CK71 You need a Phillips screwdriver to install the microSD card. 1 Press the Power button to turn off the computer.
  • Page 48 Chapter 1 — About the Computer Features 4 Slide the SIM card door to the left to unlock it and open the door. 5 Slide the microSD card door towards the top of the computer to unlock it and open the door. 70 Series Mobile Computer User Manual...

  • Page 49: Transfer Files To And From Your Pc

    Chapter 1 — About the Computer Features 6 Slide the microSD card into place. 7 Close the microSD card door and slide it towards the bottom of the computer to lock it in place. 8 Close the SIM card door and slide it to the right to lock it in place. 9 Replace the interface adapter cover and attach with the two screws removed in Step 2.

  • Page 50: Use Microsoft Activesync To Transfer Files

    Chapter 1 — About the Computer Features Use Microsoft ActiveSync to Transfer Files You can use Microsoft ActiveSync (Windows XP or earlier) or Windows Mobile Device Center (Windows Vista or Windows 7) to establish a connection between your computer and a PC. After you connect to your PC, you can transfer files, synchronize files, remotely debug, and perform other device management activities.

  • Page 51: Use The Computer As A Mass Storage Device

    3 On the mobile computer, tap Start > Settings > System > Intermec Settings. 4 From the Intermec Settings Main Menu, tap Device Settings > USB. 5 From the USB function driver menu, select Mass storage - Flash File Store and tap OK.
  • Page 52 Chapter 1 — About the Computer Features 70 Series Mobile Computer User Manual...

  • Page 53: About The User Interface And Intermec Applications

    Use this chapter to learn about the Windows Embedded Handheld user interface and how to interact with the screen. You can also use this chapter to learn about the Intermec applications on your computer, as well as additional Intermec applications you can download.

  • Page 54: About The User Interface

    Chapter 2 — About the User Interface and Intermec Applications About the User Interface The user interface for the Windows Embedded Handheld 6.5 operating system is different from previous versions of Windows Mobile. The interface is touch-friendly and easy to navigate. Use the following sections to understand how to interact with Windows Embedded Handheld 6.5.

  • Page 55: Interact With The Screen

    Chapter 2 — About the User Interface and Intermec Applications The horizontal scroll bar also replaces tabs within Windows screens and allows for easier navigation. Clock & Alarms Screen With Horizontal Scroll Bar Use the Tile bar to navigate between screens and within applications.

  • Page 56: Title Bar Status Icons

    Chapter 2 — About the User Interface and Intermec Applications Title Bar Status Icons Tappable icons in the Title bar immediately show you the status of your network, your phone, the volume, the battery, and the time. Use the following table to understand what the icons mean.
  • Page 57 Chapter 2 — About the User Interface and Intermec Applications Icon Description A UMTS network is available. Connecting to a UMTS network. A UMTS connection is active. A 3G+ network is available. An EDGE network is available. Connecting to an EDGE network.
  • Page 58 Chapter 2 — About the User Interface and Intermec Applications Icon Description Connected to a wireless network, and other networks are detected. Information about a new wireless network is available. A network connection is active. A network connection is inactive.

  • Page 59: Align The Screen

    You can also download additional applications from the Intermec website to help you use all of the features of your computer. Applications Available on the Mobile Computer Use this table to understand some of the Intermec applications available on your computer.
  • Page 60 Chapter 2 — About the User Interface and Intermec Applications Intermec Applications Available on the Mobile Computer Icon Application Description Bluetooth Use the Bluetooth Audio application to connect to Audio a Bluetooth headset or hands-free device. For more information, see “Connect to a Bluetooth Audio...

  • Page 61: Applications You Can Download To The Mobile Computer

    Chapter 2 — About the User Interface and Intermec Applications Icon Application Description ScanDiagnostic Use the ScanDiagnostic application to troubleshoot problems with the internal or external scanner. For more information, see “Use ScanDiagnostic to Troubleshoot the Scanner” on page 120.

  • Page 62: About Features Demo

    Features Demo also have separate full-featured versions that you can download and license for your computer. About Image Capture The Intermec Image Capture application is provided for use on the 70 Series computers with an EA30 imager. Image capture provides a way for users to capture a high quality grayscale image with a mobile computer.

  • Page 63: About Intermec Launcher

    RFID readers, printers and bar code scanners, located on-site or remote, to make the most of limited IT resources, and lower the total cost of ownership for Intermec data collection equipment. SmartSystems can be downloaded at no charge from the Intermec website.
  • Page 64 Chapter 2 — About the User Interface and Intermec Applications 70 Series Mobile Computer User Manual...

  • Page 65: Use The Phone

    Use the Phone You can use the phone feature to make and receive telephone calls, as well as transmit data through cellular wide-area networks (WANs).

  • Page 66: About The Phone

    Chapter 3 — Use the Phone About the Phone The 70 Series mobile computer supports two types of cellular technology: • CDMA • UMTS Note: Your Flexible Network Radio mobile computer supports both CDMA and UMTS technology. Your Flexible Network Radio does not support Network Information and Time Zone (NITZ) messages to automatically set the system time.
  • Page 67 Remove the two Phillips screws and open the card access door. 3 On the CK70, remove the two screws and lift the card access door away from the computer. 4 Slide the SIM card door to the left to unlock it and open the door.

  • Page 68: Activate The Cdma Phone

    The following table lists the carriers that Intermec currently supports. If your carrier is not listed in the table, please contact Intermec product support to see if it is now supported. Currently Supported Carriers Country...
  • Page 69 Personal > Phone > Version Information tab. The activation process is slightly different for each CDMA carrier. Your carrier sales contact and an Intermec representative can guide you through the process. After you supply the MEID to your carrier, they will respond with values that you must enter using the Windows Mobile Activation Wizard (if required).

  • Page 70: Start The Activation Wizard

    4 Tap OK when you are done configuring the options. 5 Tap OK to close Wireless Center. About Network Carriers Your Flexible Network Radio-enabled CN70, CN70e, or CK70 mobile computer contains a highly configurable WWAN platform. When you switch network carriers, or perform a clean boot, the cellular network connection is automatically configured.

  • Page 71: Switch Network Carriers

    Use the Carrier Selection application to quickly change your WWAN radio network carrier on your Flexible Network Radio-enabled CN70, CN70e, or CK70 mobile computer. 1 Tap Start > Settings > Personal > Carrier Selection. 2 Select a Carrier and tap OK. A dialog box appears asking if you want to switch carriers.

  • Page 72: Add The Wwan Connection

    If you are switching to a CDMA network, or switching from a CDMA network to a UMTS network, you must add the WWAN connection in Intermec Settings. 1 Tap Start > Settings > System > Intermec Settings > Communications > WWAN Radio. 2 Select Add New WWAN Connection.

  • Page 73: About The Network Connection

    Chapter 3 — Use the Phone 4 From Active Connection, select your Connection Name and Connect Now and tap OK. About the Network Connection Note: When you perform a clean boot, the selected carrier will default to generic UMTS. When you perform a clean boot, all user-created network connection entries are deleted, and only the generic UMTS remains.

  • Page 74: Make A Phone Call

    Chapter 3 — Use the Phone Make a Phone Call After you activate your UTMS or CDMA phone, you are ready to start making phone calls. Note: Your Flexible Network Radio mobile computer is data only. You cannot make phone calls from the Flexible Network Radio. 1 Press Phone.

  • Page 75: Use The Camera

    Use the Camera You can use the color camera to take pictures and record videos.

  • Page 76: About The Color Camera

    Chapter 4 — Use the Camera About the Color Camera The camera and flash are located on the back of the computer. You run the Pictures & Videos application to access the camera features. Note: While the Pictures & Videos application is running, you cannot use the imager.
  • Page 77 Chapter 4 — Use the Camera Setting Description Scenes Predefined scenes that optimize the camera settings for a specific environment: • DocCap: Intermec document capture. • Check: Capture images of paper checks. • Night: Low light conditions. • Cloudy: Cloudy or overcast conditions.
  • Page 78 Chapter 4 — Use the Camera Setting Description Exposure Exposure level of the image. Values are from -2.5 (darker, underexposed) to +2.5 (lighter, overexposed) in increments of 0.5. Default is 0. Brightness Brightness level of the image. Manual settings are from -4 (very dark) to +4 (very light) in increments of 1.

  • Page 79: Configure The Camera

    Chapter 4 — Use the Camera Configure the Camera Use the Pictures & Videos application to configure the camera. Note: You can also use Intermec Settings to configure some camera options. 1 Tap Start > Pictures & Video. 2 To enter Still mode, tap the Camera icon in the grid or the Camera button on the Tile bar.

  • Page 80: Take A Picture

    Chapter 4 — Use the Camera Take a Picture When you take a picture, the image is saved as a .jpg file and stored in the /My Documents/My Pictures folder. 1 Tap Start > Pictures & Videos. 2 Tap the Camera icon in the grid or the Camera button on the Tile bar, or press Enter.

  • Page 81: Save Pictures And Videos To A Microsd Card

    Chapter 4 — Use the Camera Save Pictures and Videos to a microSD Card Pictures and videos are automatically saved to the main memory on your computer. You can save your pictures and video to a microSD card to easily transport them to another device. 1 Install a microSD card.
  • Page 82 Chapter 4 — Use the Camera 70 Series Mobile Computer User Manual...

  • Page 83: Use Gps

    Use GPS The 70 Series computer comes equipped with an integrated Global Positioning System (GPS) receiver if your computer has phone capability (WWAN radio). The GPS receiver can deliver standards-based National Marine Electronics Association (NMEA) data strings to GPS applications.

  • Page 84: About The Integrated Gps On Your Computer

    Chapter 5 — Use GPS About the Integrated GPS on Your Computer Intermec recommends that you use the GPS Intermediate Driver (GPSID) instead of directly accessing the GPS hardware. The GPSID is a Microsoft software component that interacts between applications and the GPS hardware.

  • Page 85: About The Gps Module Operating Modes

    Chapter 5 — Use GPS 3 Tap Access in the horizontal scroll bar and select the Manage GPS automatically check box. 4 Tap OK. About the GPS Module Operating Modes The integrated GPS module has three operating modes: • Standalone •...

  • Page 86: Improve Gps Performance On The Computer

    The Flexible Network Radio has a maximum interval of 4. Improve GPS Performance on the Computer Use the iGPS application to improve the performance of the GPS on your CN70, CN70e, or CK70 computer. Note: Anytime you change the GPS settings, the phone module automatically resets.

  • Page 87: Configure The Computer

    Configure the Computer Use this chapter to learn about the available methods for configuring your mobile computer and how to use Intermec Settings. You can also use this chapter to learn how to configure network communications and wireless security.

  • Page 88: How To Configure The Computer

    There are several ways to configure the computer: • Directly on the computer. You can use Intermec Settings directly on the computer to change only the settings on that computer. For more information, see the next section, “Use Intermec Settings...

  • Page 89: Start Intermec Settings

    Settings Main Menu appears. About the Structure of Intermec Settings Use the tables below to help find the parameters in Intermec Settings that you want to configure. Each table contains the parameters for one of the Intermec Settings Main Menu options.
  • Page 90 Chapter 6 — Configure the Computer Data Collection Menu Data Collection Options Parameters You Can Configure • Internal Scanner Symbologies • Scanner settings • Imager settings • Decode security • Bluetooth Scanner Symbologies • Scanner settings • Imager settings • Decode security •...
  • Page 91 Chapter 6 — Configure the Computer Communications Options Parameters You Can Configure • WWAN Radio Add WWAN connection • Edit WWAN connections • Manage WWAN radio • Carrier Selection • WWAN information Serial Port Switch Serial port switch settings (IrDA, docking connector, and back interface) Device Settings Menu Device Settings Options...
  • Page 92 Chapter 6 — Configure the Computer Device Settings Options Parameters You Can Configure Profile Settings Application Whether these parameter options appear in Profile Settings: • Camera • Power • Scanning Features Disabled by Policy None (read-only) Printer Menu Printer Options Parameters You Can Configure Printer (if connected through Printer settings (Auto detect printer,...
  • Page 93 Chapter 6 — Configure the Computer Virtual Wedge Menu Virtual Wedge Options Parameters You Can Configure Enable Virtual Wedge Enable virtual wedge Bar Code Scanner Wedge Bar code scanner wedge settings (bar code scanner grid and label encoding) Magstripe Reader Wedge Magstripe Reader Grid Core Messaging Service Menu Core Messaging Service Options...

  • Page 94: Navigate In Intermec Settings

    Start menu so you can make it available to the end user for easy configuration. Use Intermec Settings to determine the profiles you want the end user to see in the Profile Settings application. 1 Go to Device Settings > Profile Settings Application.

  • Page 95: Restore Default Settings To A Menu

    After several minutes, all of the default settings are restored. Hide Menu Items in Intermec Settings You can hide items in the Intermec Settings menus if you do not want to have them available for other users to access. Hidden items are not saved when you back up your settings in the SmartSystems console.

  • Page 96: Use Intermec Settings Remotely With Smartsystems

    Chapter 6 — Configure the Computer Note: When you restore default settings in Intermec Settings, only the settings for visible items are restored to defaults. The settings for hidden menu items are not affected. Use Intermec Settings Remotely with SmartSystems...

  • Page 97: Configure 802.11A/B/G/N (Wi-Fi) Radio Communications

    By default, the 802.11 radio is disabled. Use the following procedure to enable the Wi-Fi radio using Intermec Settings. If you would like to use ScanNGo bar codes to easily enable the radio and set the default security settings, see Appendix C “ScanNGo Wi-Fi Configuration...

  • Page 98: Configure Bluetooth Communications

    You need to turn on the Bluetooth radio before you can discover and connect to other Bluetooth devices. By default, the radio is turned off. You can configure Bluetooth communications using Intermec Settings or from the Start menu. 1 Tap Start > Settings > Bluetooth > Mode.
  • Page 99 COM ports. But, if you clean boot your computer you need to recreate pairings to devices. Connect to a Bluetooth Scanner You can connect the computer to an Intermec Bluetooth scanner, such as the SF51 or SR61. 1 Tap Start > Settings > System > Wireless Scanning.
  • Page 100 Chapter 6 — Configure the Computer 2 Tap Add Device. 3 Select Quick Connect, Search, or Manual. Follow the onscreen instruction to add a wireless scanner. 70 Series Mobile Computer User Manual...

  • Page 101: Connect To A Bluetooth Printer

    • create an application that opens the wireless printing COM port on your computer. For help, see the Bluetooth Resource Kit, which is part of the Intermec Developer Library (IDL), available from the Intermec website at www.intermec.com/idl. • select the current wireless printer on your computer. For help, see the next procedure.

  • Page 102: About Serial And Usb Communications

    Chapter 6 — Configure the Computer Connect to a Bluetooth Audio Device Use the Bluetooth Audio enabler to discover, activate, and connect to Bluetooth audio devices such as a headset. This enables system sounds to be monitored through the headset. 1 Tap Start >...

  • Page 103: Create An Isp Connection

    Use this procedure to connect your mobile computer to an SR30, SR61T, or ASCII tethered scanner and enable RS-232 communications. 1 Tap Start > Settings > System > Intermec Settings > Communications > Serial Port Switch. 2 Select Standard docking and IrDA and tap OK.
  • Page 104 Chapter 6 — Configure the Computer 3 Enter a name for the connection, such as “ISP Connection.” 4 If you are using an external modem connected to your mobile computer with a cable, select Hayes Compatible on COM1 from the Select a modem list. 5 Tap Next.

  • Page 105: Create A Vpn Server Connection

    Chapter 6 — Configure the Computer Create a VPN Server Connection You can create a Virtual Private Network (VPN) connection to securely connect to servers, such as a corporate network, through the Internet. Before you can create a VPN connection, you need this information from your network administrator: •...

  • Page 106: About Wireless Security

    LEAP • This section explains how to configure wireless security on your mobile computer. Intermec recommends that you implement WPA2 security using PSK (Personal) or 802.1X (Enterprise) key management as appropriate. You must use either Funk or Microsoft security to implement your security solution.

  • Page 107: Select A Funk Security Profile

    By default, the active profile is Profile 1. Select a Funk Security Profile Use the following procedure to select a Funk security profile. 1 Start Intermec Settings. 2 Select Communications > 802.11 Radio > Funk Security. 3 Select a profile. A list of configurable settings appears.
  • Page 108 1 Make sure the communications and radio parameters on your computer are configured. 2 Make sure Funk is selected as your security choice. 3 Start Intermec Settings. 4 Select Communications > 802.11 Radio > Funk Security. 5 Select the profile you want to configure.
  • Page 109 9 Save your settings. Configure 802.1x Security with Funk Security Use the following procedure to configure 802.1x-WEP security with Funk security. Intermec recommends that you use WPA2-802.1x instead of 802.1x-WEP if possible. 1 Make sure the communications and radio parameters on your computer are configured.
  • Page 110 8 Save your settings. Configure Static WEP Security with Funk Security Use the following procedure to configure static WEP security with Funk. Intermec recommends that you use WPA2-PSK instead of WEP if possible. 1 Make sure the communications and radio parameters on your computer are configured.

  • Page 111: Select Microsoft As Your Security Choice

    Use Open (No Security) Associations with Funk Use the following procedure to configure your mobile computer for open security using Funk. 1 Start Intermec Settings. 2 Select Communications > 802.11 Radio > Funk Security. 3 Select the active profile you are using.
  • Page 112 • Static WEP Select Microsoft Security Use the following procedure to select Microsoft security. 1 Start Intermec Settings. For help, see “Configure the Computer” on page 2 Select Communications > 802.11 Radio > Security Choice. 3 From the Security Choice list, select Microsoft Security. An alert box appears telling you that you must save your settings and reboot the computer for the new security choice to take effect.
  • Page 113 Security. 1 Make sure the communications and radio parameters on your computer are configured. 2 Start Intermec Settings. 3 Select Communications > 802.11 Radio > Microsoft Security. 4 For Infrastructure Mode, select Infrastructure. 5 For Network Authentication, select WPA-PSK. Data Encryption automatically defaults to TKIP for WPA and AES for WPA2.
  • Page 114 7 Save your settings. Configure 802.1x Security with Microsoft Use the following procedure to configure 802.1x security with Microsoft security. Intermec recommends that you use WPA2-802.1x instead of 802.1x-WEP if possible. 1 Make sure the communications and radio parameters on your computer are configured.
  • Page 115 11 Save your settings. Configure Static WEP Security with Microsoft Use the following procedure to configure static WEP security with Microsoft security. Intermec recommends that you use WPA2-PSK instead of WEP if possible. 1 Make sure the communications and radio parameters on your computer are configured.

  • Page 116: Load A Certificate

    They contain a public key and the entity name that owns the key. Each certificate is issued by a certificate authority. 1 Start Intermec Settings. 2 Go to Start > Settings > System > Intermec Settings. 70 Series Mobile Computer User Manual...
  • Page 117 Chapter 6 — Configure the Computer 3 Tap Communications > 802.11 Radio > Certificates. The Certificates screen appears. 4 To import a certificate chain: a Tap Import Certificates to install the selected certificate. b In the CertImportUI screen, tap the <<< button next to the Select pfx to import text field.
  • Page 118 Chapter 6 — Configure the Computer 70 Series Mobile Computer User Manual...

  • Page 119: Manage The Computer

    Manage the Computer Use this chapter to learn how to remotely update, configure, and monitor your Intermec mobile computers. You will also find information on installing and developing software applications as well as how to upgrade the system software.

  • Page 120: Manage The Computer In Your Network

    Manage the Computer Using CloneNGo Intermec CloneNGo is a software application that allows you to copy the settings and parameters from a master computer onto one or more client computers. Cloning reduces redundancy and error by providing...
  • Page 121 You can download SmartSystems from the Intermec website at no charge. For more information, visit www.intermec.com/SmartSystems. To purchase a Provisioning license, contact your local Intermec sales representative.

  • Page 122: Manage The Computer Using Third-Party Software

    Develop and Install Applications Use the Intermec Resource Kits to develop applications to run on the mobile computer. The Resource Kits are a library of C++, .NET, Java, and web components grouped by functionality that you can use to create applications for the computer.

  • Page 123: Install Applications Using Smartsystems Foundation Console

    You can use the SmartSystems console to drag-and-drop Intermec applications onto your mobile computer. The console is part of SmartSystems Foundation. 1 Download your application file from the Intermec website and unzip it on your desktop PC. 2 Double-click the application file to install it. The application file should appear in the Software Vault.

  • Page 124: Install Applications Using A Storage Card

    Chapter 7 — Manage the Computer 3 Reboot or cold boot the computer. 4 After the boot process is finished, browse to the .cab files and tap the files to install them. Install Applications Using a Storage Card Use a storage card to install applications on one computer at a time or if you have no network connection.

  • Page 125: Update Individual Or Multiple Computers Using The Smartsystems Console

    You can use the SmartSystems console to update the operating system or system software on your mobile computer. The console is part of SmartSystems Foundation and is available from the Intermec website. Before you can update your mobile computer, you need: •...

  • Page 126: Update Individual Mobile Computers Using A Microsd Card

    Before you can update your mobile computer, you need: • the SmartSystems bundles you want to install. These SmartSystems bundles are available from the Intermec website at www.intermec.com. Go to Support > Downloads > OS/Firmware/Drivers list. •...

  • Page 127: Troubleshoot And Maintain The Computer

    Troubleshoot and Maintain the Computer If you encounter any problems while using the 70 Series computer, look in this chapter to find a possible solution. You will also find information on routine maintenance.

  • Page 128: About The Intermec Dashboard

    Chapter 8 — Troubleshoot and Maintain the Computer About the Intermec Dashboard The Intermec Dashboard is designed to provide proactive monitoring of your mobile computers to prevent downtime. You can easily see the health of the device and can help pinpoint the source of a problem to determine if it is hardware or software related.

  • Page 129: Troubleshoot Your Mobile Computer

    If you send the computer in for service, it is your responsibility to save the computer data and configuration. Intermec is responsible only for ensuring that the hardware matches the original configuration when repairing or replacing the computer.

  • Page 130: Troubleshoot 802.1X Security

    Make sure the network name matches the access point network name. Default network name is “INTERMEC.” The access point may not be communicating with the server. Ensure the access point is turned on, properly configured, and has 802.1x security enabled.

  • Page 131: Check 802.11 Network Status

    Follow the next procedure to verify available access points and networks, check signal strength, and view other diagnostics. If you need to contact Intermec Product Support, this information can be helpful in troubleshooting wireless network connection issues. 1 Tap Start > iSpyWiFi. The ISpyWiFi application launches.

  • Page 132: Troubleshoot Reading Bar Codes

    • The imager hardware trigger might be disabled in Intermec Settings. To check the setting go to Start > Settings > Systems > Data Collection > Scanner Settings. Hardware trigger should be checked.
  • Page 133 Good Read light remains on, there may be a problem. Press one of the Scan buttons or pull the trigger again without scanning a bar code label. If the light is still on, contact your local Intermec representative. •...

  • Page 134: Use Scandiagnostic To Troubleshoot The Scanner

    Chapter 8 — Troubleshoot and Maintain the Computer Use ScanDiagnostic to Troubleshoot the Scanner Use the ScanDiagnostic application to troubleshoot problems such as the inability to read a bar code or a scanner that does not turn on. 1 From the Home menu, tap Start > ScanDiagnostic. 2 From the Scan Health screen, select the scanner you want to troubleshoot and then tap Diagnose.
  • Page 135 System Software” on page 110. • If the computer does not boot or reset, contact your Intermec representative for help. The accelerometer does not You may need to calibrate the accelerometer using the Sensor appear to be accurate. Calibration application. Tap Start > Settings > System >...

  • Page 136: Call Product Support

    If you still need help after visiting Knowledge Central, you may need to call Product Support. To talk to an Intermec Product Support representative, call: 1-800-755-5505 Before you can call Intermec Product Support, make sure you have the following information ready: • Configuration number •...

  • Page 137: Find Your Operating System Version

    Find Your Operating System Version Use the following procedure to find the OS version of your mobile computer. 1 Press the Intermec Dashboard ( ) button to launch the Dashboard. 2 Tap the Information bar. The Information Details page appears and displays information such as the firmware version and the OS version.
  • Page 138 3 Press the Reset button in the battery compartment on the back of the computer. Location of CN70/CN70e Reset Button Reset button Location of CK70/CK71 Reset Button Reset button 4 Replace the battery and the handstrap. 5 Press Power and wait while the mobile computer boots. When the cold boot is complete, the Home screen appears.

  • Page 139: Clean Boot The Computer

    You can perform a clean boot using the mobile computer. Note: You can also perform a clean boot using the SmartSystems Console. Right-click the 70 Series computer and select Intermec Power Tools > Clean Boot Device. 1 Remove the battery pack from the back of the computer.
  • Page 140 Chapter 8 — Troubleshoot and Maintain the Computer 1 Press the Power button and choose to suspend the computer. 2 Dip a clean cloth towel in the ammonia solution and wring out the excess. 3 Wipe off the imager window, camera lens, and flash area. Do not allow any abrasive material to touch these surfaces.

  • Page 141: Specifications And Default Settings

    Specifications and Default Settings...

  • Page 142: Physical And Environmental Specifications

    Dimensions 19.5 x 8.0 x 3.4 cm (7.66 x 3.14 x 1.35 in) Weight 491 g (16.6 oz) with battery CK70 Physical Dimensions Dimensions 23.7 x 8.0 x 4.3 cm (9.33 x 3.16 x 1.69 in) Weight 562 g (19 oz) with battery CK71 Physical Dimensions Dimensions 23.7 x 8.0 x 5.0 cm (9.33 x 3.16 x 1.98 in)

  • Page 143: Power And Electrical Specifications

    Battery type Rechargeable Lithium-ion (Li-ion) battery Battery capacity CN70/CN70e: 3.7 V, 4000 mAh (14.8 Wh) CK70/CK71: 3.7 V, 5200 mAh (19.2 Wh) Electrical rating x 4.37/4.8 V; 2/1,5 A 70 Series Non-Incendive Computer Specifications The 70 Series mobile computers with non-incendive (NI) certification comply with the following specifications for North America and Canada regions only.

  • Page 144: Hardware

    5 megapixel color camera and EA30 area imager (all), EV12 (CK71 only), or EX25 (CK71 only) Back Accessory Interface Pin-outs The back accessory interface provides power for peripheral devices out the back of the CK70 and CK71 computers. Pin Name Description OTB_PWR...

  • Page 145: Standard Communications

    Appendix A — Specifications and Default Settings Standard Communications • UMTS (not available on CK71) • CDMA (not available on CK71) • Flexible Network Radio (not available on CK71) • GPS (not available on CK71) • 802.11a/b/g/n • Bluetooth • USB Full Speed V2.0 Host •...

  • Page 146: Bar Code Symbologies

    Appendix A — Specifications and Default Settings Bar Code Symbologies imagers support all of the bar code symbologies listed in the next table. Supported Bar Code Symbologies AustraliaPost* GS1 DataBar Omni-Directional Aztec* Infomail* BPO* Interleaved 2 of 5 Canada Post* Japan Post* China Post* KoreanPost*...

  • Page 147: Imager Reading Distances

    (4 lux). Minimum distances are measured in the dark (0 lux). Both reading distances are provided in respective scan engine integration guides. Contact your local Intermec representative for more information. Below are the typical and minimum standard reading distances for the 70 Series computer built with an EA30 imager.
  • Page 148 Appendix A — Specifications and Default Settings EA30 Typical Reading Distances - Extended Reading Range These typical reading distances are measured in an office environment (250 lux) for the EA30 standard model with Extended Reading Range activated. Extended Reading Range is enabled by default. EA30 Typical Reading Distances - Extended Reading Range Activated 0"...

  • Page 149: Ea30 Area Imager Minimum Reading Distances

    Appendix A — Specifications and Default Settings EA30 Area Imager Minimum Reading Distances Minimum distances are measured in the dark (0 lux). 0" 4" 8" 12" 16" 20" 24" 28" 12" Data Matrix 10 mils 8" PDF417 10 mils 4" 0"...
  • Page 150 Appendix A — Specifications and Default Settings EA30 Area Imager Typical Reading Distances Typical distances are measured in an office environment (250 lux). 0" 4" 8" 12" 16" 20" 24" 28" 32" 36" 12" Data Matrix 10 mils 8" PDF417 10 mils 4"...
  • Page 151 Appendix A — Specifications and Default Settings EV12 Linear Imager Minimum Reading Distances The illustration below does not include the 0.12 cm (0.05 in) setback for the CK71. Minimum reading distances are measured in the dark (0 lux). 0" 4" 8"...
  • Page 152 Appendix A — Specifications and Default Settings EV12 LInear Imager Typical Reading Distances The illustration below does not include the 0.12 cm (0.05 in) setback for the CK71. Typical reading distances are measured in an office environment (200 lux). 0" 8"...
  • Page 153 Appendix A — Specifications and Default Settings EX25 Near-Far Range Imager Minimum Reading Distance Minimum reading distances are measured in the dark (0 lux). The following graphic does not include the 0.24 cm (0.09 in) setback for the CK71. 144” 160”...
  • Page 154 Appendix A — Specifications and Default Settings EX25 Near-Far Range Imager Typical Reading Distance Typical reading distances are measured in an office environment (200 lux). The following graphics do not include the 0.24 cm (0.09 in) setback for the CK71. EX25 Near-Far Range Imager 1D Typical Reading Distances 80”...
  • Page 155 Appendix A — Specifications and Default Settings EX25 1D Symbologies Typical Reading Distances With 0.24 cm (0.09 in) Setback Symbology Density Minimum Distance Maximum Distance Code 39 0.25 mm (10 mils) 15 cm (5.91 in) 135 cm (53.15 in) 0.5 mm (20 mils) 16 cm (6.30 in) 280 cm (110.24 in) 1 mm (40 mils)

  • Page 156: Default Configuration

    The settings are grouped by function and reflect the organization of Intermec Settings. Not all of the configuration settings are listed in this appendix. For detailed information on most of the settings, see the Intermec Settings Command Reference Manual.
  • Page 157 Appendix A — Specifications and Default Settings Symbology Settings Symbology Default Value AustraliaPost Disable Aztec Disable Disable CanadaPost Disable Codabar Disable Codablock A Disable Codablock F Disable Code 11 Disable Code 39 Enable Code 93 Disable Code 128/GS1-128 Enable DataMatrix Enable DutchPost Disable...
  • Page 158 Appendix A — Specifications and Default Settings Symbology Default Value Standard 2 of 5 Disable SwedenPost Disable Telepen Disable TLC 39 Disable Symbology Option Settings Symbology Option Settings Default Value Preamble None (Disabled) Postamble None (Disabled) Symbology Identifier Disable Multicode Disable Scanner Settings Scanner Settings...

  • Page 159: Communications

    Appendix A — Specifications and Default Settings Imager Settings Default Value Image Capture Output Compression Bitmap Output Compression Quality Edge Enhancement None Noise Reduction Subsampling None Image Rotation None Image Lighting Correction Disable Decode Security Settings Decode Security Settings Default Value Consecutive Data Validation Identical Consecutive Timeout 300 ms...

  • Page 160: Device Settings

    Appendix A — Specifications and Default Settings 802.11 Radio Setting Default Value Import User Certificates False Import Pac Files False Radio Bands b/g (2.4 GHz) Radio Enabled Ethernet Adapter Settings Ethernet Adapter Setting Default Value DHCP Enabled Bluetooth Settings Bluetooth Setting Default Value Bluetooth Power WWAN Radio Settings...
  • Page 161 Appendix A — Specifications and Default Settings Good Read Settings Good Read Setting Default Value Internal Scanner Good Read Beep One Beep Tethered Scanner One Beep Bluetooth Scanner Good Read Beep One Beep Backlight Settings Backlight Setting Default Value Display Backlight Adjustment Normal Keypad Backlight On Based on Light Level...
  • Page 162 Appendix A — Specifications and Default Settings Power Management Settings Power Management Setting Default Value Enable Power Button Screen Screen Options Displayed Hibernate, Suspend, Reboot Screen Timeout (Seconds) Power Button Behavior Suspend Device Turns Off After (Battery Power) 5 minutes Screen Turns Off After (Battery Power) Disabled Device Turns Off After (External Power) Disabled...

  • Page 163: Gps Settings

    Core Messaging Service Core Messaging Service Setting Default Value Associated Server IP Null Broadcast Name INTERMEC Port 62241 Keep Alive Ping Interval 30 Seconds Device Monitor Settings Use device monitor settings to configure how the mobile computer monitors the network.

  • Page 164: Virtual Wedge Settings

    Appendix A — Specifications and Default Settings Device Health Screen Captures Device Health Screen Captures Setting Default Value Directory \SmartSystems\ScreenCapture Screen Captures Allowed Device Wipe Device Wipe Setting Default Value Enable Wipe Disabled Interval (in days) Null Virtual Wedge Settings Use virtual wedge settings to configure the virtual wedge.

  • Page 165: Keypads And Keystrokes

    Keypads and Keystrokes...

  • Page 166: Standard Characters

    Appendix B — Keypads and Keystrokes Standard Characters Use the following tables to learn how to enter standard and other available characters and functions with the keypad. If there is no sequence of keystrokes for a particular character or function, it is only available through the soft input panel (SIP), which you can access by tapping the keyboard icon on the touch screen.
  • Page 167 Appendix B — Keypads and Keystrokes Character Numeric Keypad QWERTY Keypad c 6 6 c 6 6 6 c 7 7 c 7 7 7 c 7 7 7 7 c 8 8 c 8 8 8 c 9 9 c 9 9 9 c 9 9 9 9 c 1 2...
  • Page 168 Appendix B — Keypads and Keystrokes Character Numeric Keypad QWERTY Keypad c 1 4 4 4 c 1 5 c 1 5 5 c 1 5 5 5 c 1 6 c 1 6 6 c 1 6 6 6 c 1 7 c 1 7 7 c 1 7 7 7...
  • Page 169 Appendix B — Keypads and Keystrokes Character Numeric Keypad QWERTY Keypad CN70 Characters and Functions To Enter Numeric Keypad QWERTY Keypad @ (at symbol) & (ampersand) * (asterisk) : (colon) , (comma) $ (dollar) ! (exclamation) - (hyphen) % (percent) .
  • Page 170 Appendix B — Keypads and Keystrokes To Enter Numeric Keypad QWERTY Keypad ? (question mark) ‘ (apostrophe) Forward Tab Backspace Up Arrow Down Arrow Left Arrow Right Arrow CapsLock Enter Shift Space Start (Windows) Talk End Call Intermec Dashboard 70 Series Mobile Computer User Manual...

  • Page 171: Cn70E Keypads And Keystrokes

    Appendix B — Keypads and Keystrokes CN70e Keypads and Keystrokes CN70e Alphanumeric Characters Character Numeric Keypad Calculator-Style Keypad QWERTY Numeric Keypad c 2 2 c 8 8 c 2 2 2 c 8 8 8 c 3 3 c 9 9 c 3 3 3 c 9 9 9 c 4 4...
  • Page 172 Appendix B — Keypads and Keystrokes Character Numeric Keypad Calculator-Style Keypad QWERTY Numeric Keypad c 8 8 c 2 2 c 8 8 8 c 2 2 2 c 9 9 c 3 3 c 9 9 9 c 3 3 3 c 9 9 9 9 c 3 3 3 3 Z c 1 2 c 7 8...
  • Page 173 Appendix B — Keypads and Keystrokes Character Numeric Keypad Calculator-Style Keypad QWERTY Numeric Keypad c 1 6 6 6 c 7 6 6 6 y O c 1 7 c 7 1 c 1 7 7 c 7 1 1 c 1 7 7 7 c 7 1 1 1 y R c 1 7 7 7 c 7 1 1 1...
  • Page 174 Appendix B — Keypads and Keystrokes Character Numeric Keypad Calculator-Style Keypad QWERTY Numeric Keypad CN70e Characters and Functions Calculator-Style To Enter Numeric Keypad Keypad QWERTY Numeric Keypad @ (at symbol) & (ampersand) * (asterisk) : (colon) , (comma) $ (dollar) ! (exclamation) - (hyphen) % (percent)

  • Page 175: Ck70 Keypads And Keystrokes

    Right Arrow CapsLock Enter Shift Space c m b m c m b m Start (Windows) Talk End Call Intermec Dashboard CK70 Keypads and Keystrokes CK70 Alphanumeric Characters Character Large Alpha Keypad Alphanumeric Keypad 70 Series Mobile Computer User Manual...
  • Page 176 Appendix B — Keypads and Keystrokes Character Large Alpha Keypad Alphanumeric Keypad 70 Series Mobile Computer User Manual...
  • Page 177 Appendix B — Keypads and Keystrokes Character Large Alpha Keypad Alphanumeric Keypad 70 Series Mobile Computer User Manual...
  • Page 178 Appendix B — Keypads and Keystrokes Character Large Alpha Keypad Alphanumeric Keypad CK70 Characters and Functions To Enter Large Alpha Keypad Alphanumeric Keypad @ (at symbol) & (ampersand) 70 Series Mobile Computer User Manual...
  • Page 179 Appendix B — Keypads and Keystrokes To Enter Large Alpha Keypad Alphanumeric Keypad * (asterisk) : (colon) ; (semicolon) , (comma) $ (dollar) ! (exclamation) - (hyphen or minus) % (percent) . (period) + (plus) # (pound) ? (question mark) ‘...
  • Page 180 Appendix B — Keypads and Keystrokes To Enter Large Alpha Keypad Alphanumeric Keypad ~ (tilde) \ (backslash) / (forward slash) “ (quotes) ( (left parenthesis) ) (right parenthesis) Insert Delete ¦ (broken vertical bar) ̀ (grave) Forward Tab Backspace Up Arrow Down Arrow Left Arrow Right Arrow...
  • Page 181 To Enter Large Alpha Keypad Alphanumeric Keypad Space Start (Windows) Ctrl Ctrl Ctrl Send Call End Call Intermec Dashboard CK70 Function Keys To Enter Large Alpha Keypad Alphanumeric Keypad ¡ ¢ £ ¤ ¥ b ¡ b ¢ b £...

  • Page 182: Ck71 Keypads And Keystrokes

    Appendix B — Keypads and Keystrokes To Enter Large Alpha Keypad Alphanumeric Keypad CK71 Keypads and Keystrokes CK71 Alphanumeric Characters Character Numeric With Function Keys Keypad Alphanumeric Keypad 70 Series Mobile Computer User Manual...
  • Page 183 Appendix B — Keypads and Keystrokes Character Numeric With Function Keys Keypad Alphanumeric Keypad b ¡ b ¢ b £ b ¤ b ¥ b ¦ b § b ¨ b © b ª b « b ¬ Ctrl b y 7 70 Series Mobile Computer User Manual...
  • Page 184 Appendix B — Keypads and Keystrokes Character Numeric With Function Keys Keypad Alphanumeric Keypad b y 8 b y 9 b y 4 b y 5 b y 6 b y 1 b y 2 b y 3 b y 0 b y - b y ¡...
  • Page 185 Appendix B — Keypads and Keystrokes Character Numeric With Function Keys Keypad Alphanumeric Keypad b y ¬ b y m Ctrl CK71 Characters and Functions To Enter Numeric With Function Keys Keypad Alphanumeric Keypad : (colon) ; (semicolon) , (comma) $ (dollar) ! (exclamation) 70 Series Mobile Computer User Manual...
  • Page 186 Appendix B — Keypads and Keystrokes To Enter Numeric With Function Keys Keypad Alphanumeric Keypad - (hyphen or minus) . (period) + (plus) ‘ (apostrophe) = (equals) _ (underscore) > (greater than) < (less than) [ (left square bracket) ] (right square bracket) { (left curly brace) } (right curly brace) ~ (tilde)
  • Page 187 Backspace Up Arrow Down Arrow Left Arrow Right Arrow CapsLock Enter Shift Space Start (Windows) Ctrl Ctrl Ctrl Intermec Dashboard CK71 Function Keys To Enter Numeric With Function Keys Keypad Alphanumeric Keypad ¡ ¡ ¢ ¢ £ £ ¤ ¤...
  • Page 188 Appendix B — Keypads and Keystrokes To Enter Numeric With Function Keys Keypad Alphanumeric Keypad ¥ ¥ ¦ b ¡ § b ¢ ¨ b £ © b ¤ ª b ¥ « ¬ c ¡ c ¢ c £ c ¤...
  • Page 189 Appendix B — Keypads and Keystrokes CK71 Intermec Terminal Emulation (ITE) Keys To Enter Numeric With Function Keys Keypad Alphanumeric Keypad Attention c ¤ Autolog Clear Duplicate c ¥ EEOF Erase Find Field + Field - Fieldmark Help Home Keypad...
  • Page 190 Appendix B — Keypads and Keystrokes To Enter Numeric With Function Keys Keypad Alphanumeric Keypad c £ Page Print Previous Screen Remove Reset Return Roll Down Roll Up System Request View View Down View Up 70 Series Mobile Computer User Manual...

  • Page 191: Scanngo Wi-Fi Configuration Bar Codes

    ScanNGo Wi-Fi Configuration Bar Codes You can use the ScanNGo Wi-Fi configuration bar codes to quickly configure the 802.11 radio in your computer.

  • Page 192: Radio Configuration Bar Codes

    The CN70, CN70e, and CK70 are available with the EA30 imager only. The CK71 has three imager options: the EA30, EX25, or EV12 imager. If your CK71 has an EA30 or EX25 imager, use the 2D configuration bar codes to configure the radio.

  • Page 193: Configuration Bar Codes

    Appendix C — ScanNGo Wi-Fi Configuration Bar Codes 2D Imager Radio Configuration Bar Codes When You Want To: Scan This Bar Code • Set all communication settings to defaults (Wi-Fi, WWAN if applicable) • Enable Wi-Fi - set Funk defaults 1D Configuration Bar Codes You can configure the computer with a 1D imager (EV12).
  • Page 194 Appendix C — ScanNGo Wi-Fi Configuration Bar Codes 1D Imager Radio Configuration Bar Codes When You Want To: Scan This Bar Code • Set all communication settings to defaults (Wi-Fi, WWAN if applicable) • Enable Wi-Fi - set Funk defaults 70 Series Mobile Computer User Manual...
  • Page 195 Appendix C — ScanNGo Wi-Fi Configuration Bar Codes When You Want To: Scan This Bar Code • Set all communication settings to defaults (Wi-Fi, WWAN if applicable) • Enable Wi-Fi - set Funk defaults 70 Series Mobile Computer User Manual...
  • Page 196 Appendix C — ScanNGo Wi-Fi Configuration Bar Codes When You Want To: Scan This Bar Code • Set all communication settings to defaults (Wi-Fi, WWAN if applicable) • Enable Wi-Fi - set Microsoft WZC defaults 70 Series Mobile Computer User Manual...
  • Page 197 Appendix C — ScanNGo Wi-Fi Configuration Bar Codes When You Want To: Scan This Bar Code • Set all communication settings to defaults (Wi-Fi, WWAN if applicable) • Enable Wi-Fi - set Microsoft WZC defaults 70 Series Mobile Computer User Manual...
  • Page 198 Appendix C — ScanNGo Wi-Fi Configuration Bar Codes 70 Series Mobile Computer User Manual...

  • Page 199: Index

    Index...
  • Page 200 ActiveSync charging accessories establishing a partnership checking the status using to install applications conserving battery life aligning the screen described alpha keypad, CK70, illustrated status LED alphanumeric keypad Bluetooth CK70, illustrated Audio application described CK71, illustrated audio device, connecting to...
  • Page 201 SmartSystems, using to entering on CK70/CK71 keypad install applications contact information, Intermec entering on numeric keypad entering on QWERTY keypad Dashboard – entering with keystrokes...
  • Page 202 Intermec Browser, described configuring LEAP Intermec Connection Manager, configuring static WEP described configuring WPA Enterprise Intermec Dashboard, about (802.1x) Intermec Developer Library (IDL) configuring WPA Personal (PSK) Intermec Launcher, described configuring WPA2 Enterprise Intermec Resource Kits (802.1x) described configuring WPA2 Personal...
  • Page 203 CDMA, activating installing in a CK70/CK71 features installing in a CN70/CN70e making a call updating system software making an emergency call using to save pictures and videos turning on and off...
  • Page 204 RS-232 snap-on adapter, described Console, using to install applications downloading monitoring computer health scan handle, described ScanDiagnostic updating system software Intermec application described using with remote Intermec Settings using to troubleshoot specifications scanner non-incendive (NI) Bluetooth, connecting to physical and environmental default settings...
  • Page 205 Index Suspend, power option described Wavelink Avalanche, downloading symbologies, supported the enabler system software updating with microSD card static, configuring with Funk static, configuring with updating with SmartSystems Microsoft Foundation WiFi communications, supported Wi-Fi radio, enabling Wi-Fi, troubleshooting terminal emulation, Windows Embedded Handheld, troubleshooting user interface...
  • Page 206 Index www.intermec.com Product Support Knowledge Central warranty information manuals, downloading 70 Series Mobile Computer User Manual...
  • Page 208 Worldwide Headquarters 6001 36th Avenue West Everett, Washington 98203 U.S.A. tel 425.348.2600 fax 425.355.9551 www.intermec.com © 2012 Intermec Technologies Corporation. All rights reserved. 70 Series Mobile Computer User Manual *935-038-005* P/N 935-038-005...

This manual is also suitable for:

Ck70niCk71Ck71niCn70niCn70eCn70eni ... Show all

Table of Contents
