UM2248
7.12
MIPI DSI
A TFT color LCD with the MIPI DSI
connector. Refer to
7.13

JTAG connector (CN17)

Pin
number
1
3
5
7
9
11
13
15
17
19
®
display connector (CN16)
Section 6.29
for detail.

Figure 19. JTAG/SWD debugging connector (CN17) top view

19
17
15
20
18
16

Table 39. JTAG/SWD debugging connector (CN17)

Description
VDD power
PB4
PA15
PA13
PA14
NC
PB3
RESET#
-
-
UM2248 Rev 5
®
interface daughterboard is mounted on the CN16
13
11
9
7
5
14
12
10
8
Pin
number
2
4
6
8
10
12
14
16
18
20
3
1
6
4
2
Description
VDD power
GND
GND
GND
GND
GND
GND
GND
GND
GND
Connectors
MSv30722V2
61/77
76
