Specifications

8.1.2 Derating for Temperature

The frequency converter automatically derates the
switching frequency, switching type, or output current
under certain load or ambient conditions as described
below. The derating curves in Illustration 8.1 apply to both
SFAVM and 60 AVM switching modes.

8.2 Mechanical Dimensions

1581
[62.2]
1021.9
[40.2]
Illustration 8.2 Frame Size D13
MG16I202
Operating Instructions
110
100
90
80
70
60
50
0.0
Illustration 8.1 Derating Frame Sizes D, E, and F 380-500 V
(T5) Normal Overload 110%
60.0
[6.3]
977.0
1534.5
[60.4] [38.5]
1780.5
[70.1]
112.5
[4.4]
377.8
[14.9]
Danfoss A/S © Rev. 2014-07-29 All rights reserved.
0.5 1.0 1.5 2.0 2.5
510.0
304.0
[20.1]
[12.0]
304.0
[12.0]
160.0
[6.3]
184.5
369.0
[7.3]
486.4
[14.5]
[19.2]
627.4
[24.7]
o
40 C
o
45 C
o
50 C
55 C o
3.0 3.5 4.0
8
139.0
[5.5]
1755.5
[69.1]
411.0
[16.2]
251.0
[9.9]
117.5
301.9
[4.6]
[11.9]
75
