MCTRL660 PRO Independent Controller
User Manual
The MCTRL660 PRO is powerful and easy to use. You can quickly configure the LED
screen to light it up and display the entire input source following steps in
Screen
screen display effect.
Instruction on knob operations:




Quick Screen Configuration

Following the steps below, namely Setting Input Source > Setting Input
Resolution > Quickly Configuring Screen, you can quickly light up the LED screen
to display the entire input source.

8.1.1 Step 1 Setting Input Source

Supported input sources include 3G-SDI, Single-Link DVI and HDMI 1.4a. Select an
input source that matches the type of the inputted external video source.
Constraints on input sources:



www.novastar.tech
Configuration. With other menu settings, you can further improve the LED
Press the knob to enter a menu page or confirm an operation.
Rotate the knob to select a menu item or adjust a menu parameter.
Hold the knob and BACK button simultaneously for 5 seconds to lock or unlock
all the buttons.
Only one video input source can be selected at the same time.
Interlaced SDI video sources do not support low latency.
SDI video sources do not support the following functions:
− Color depth adjustment
− Image mirroring
Contrast, saturation and hue adjustment
−
8

Menu Operations

8 Menu Operations
8.1 Quick
