MCTRL660 PRO Independent Controller

User Manual

9.3.2 SmartLCT

Connect the MCTRL660 PRO to the control computer installed with SmartLCT V3.2.0

or later via USB cable to perform building-block cabinet configuration, seam

brightness adjustment, real-time monitoring, hot backup, etc. For details on their

operations, see SmartLCT User Manual.

Figure 9-2 User interface of SmartLCT

In NovaLCT, perform the following steps to update the MCTRL660 PRO firmware.

Step 1 Start NovaLCT and choose User > Advanced Synchronous System User Login

and log in as an advanced user.

Step 2 Type the secret code "admin" to enter the program loading page.

Step 3 Click Browse to select the update program path and then click Update.

9.4.2 SmartLCT

In SmartLCT, perform the following steps to update the MCTRL660 PRO firmware.

Step 1 Start SmartLCT and enter the V-Sender page.

Step 2 In the properties area on the right, click

Step 3 Click

Step 4 Click Update.

www.novastar.tech

to select the update program path.

9 Operations on PC

to enter the Firmware Upgrade page.
