MCTRL660 PRO Independent Controller
User Manual
The MCTRL660 PRO is a professional controller developed by NovaStar. A single
MCTRL660 PRO has a loading capacity of up to 1920×1200@60Hz. It allows users
to customize resolutions to configure ultra-large screens with ultra-width or ultra-
height.
The MCTRL660 PRO has various video connectors:



The MCTRL660 PRO has many industry-leading advanced technologies:






The MCTRL660 PRO is mainly used for the rental and fixed fields, such as concerts,
live events, security monitoring centers, Olympic Games and various sports centers.
www.novastar.tech
Input connectors: 1 × 3G-SDI, 1 × HDMI 1.4a, 1 × single-link DVI
Output connectors: 6 × Gigabit Ethernet ports, 2 × 10G optical ports
Loop output connectors: 1 × 3G-SDI LOOP, 1 × HDMI 1.4a LOOP, 1 × DVI
LOOP
Input of ultra-high color depths, such as 10-bit/12-bit 4:4:4, with input resolutions
up to 1920×1080@60Hz, increasing color expression capabilities by 4096 times
compared to 8-bit inputs, and presenting images with rich and delicate colors,
smoother transitions, as well as clearer details
Individual Gamma adjustment for RGB, effectively controlling image non-
uniformity under low grayscale and white balance offset to improve image quality
A low latency of less than 1 frame (≤ 10 lines)
Dual working modes: working as sending card and fiber converter
One-click backup and recovery, quickly recovering previous screen
configurations to deal with sudden on-site failure.
Image mirroring, allowing for more cool and dazzling stage effects
