MCTRL660 PRO Independent Controller
User Manual
Output
MONITOR
Control
Power
Dimensions
www.novastar.tech
6
2
1
1
1
1
1
1
1
1
1
1
6 Hardware Structure
RJ45 (Gigabit Ethernet ports)
OPT1/OPT2 (10G optical ports)
DVI LOOP
HDMI LOOP
3G-SDI LOOP
HDMI (Output)
GENLOCK IN
GENLOCK LOOP
ETHERNET (Fast Ethernet port)
USB IN
USB OUT
100 V–240 V AC
Unit: mm
9
